Convolution & Correlation: The Workhorse Operation

"People keep asking whether I flip before I slide. After forty years in this business, I can tell you: with a symmetric kernel, nobody can tell, and with an asymmetric one, nobody checks."

A Slightly Flipped Convolution Kernel

In Chapter 2 every output pixel was a function of exactly one input pixel: $g(x, y) = T(f(x, y))$. That restriction made point operations fast and simple, but it also made them blind. A point operation cannot reduce noise, because at a single pixel there is no way to distinguish noise from signal; it cannot detect an edge, because an edge is by definition a relationship between neighboring pixels. This section takes the step that changes everything: the output at $(x, y)$ now depends on a whole neighborhood of input pixels around $(x, y)$. The rest of Part I, and a striking fraction of Parts III and IV, is the study of what becomes possible once that step is taken.

1. From Points to Neighborhoods Beginner

A neighborhood operation computes each output pixel from a small window of input pixels, almost always a square window centered on the output position. The simplest useful example: replace every pixel with the average of the $3 \times 3$ block around it. Noise that fluctuates up at one pixel and down at its neighbor partially cancels in the average, while the underlying scene, which varies slowly, survives. That is already a working denoiser, and we will refine it in Section 3.2.

The key abstraction is to separate the pattern of weights from the sliding machinery. The weights live in a small matrix called a kernel (also: filter, mask, window, or in the deep learning literature, a filter bank entry). The machinery, identical for every kernel, slides the kernel across the image and computes a weighted sum at each stop. Change the kernel and the same machinery blurs, sharpens, differentiates, or detects patterns. This is precisely the design of a convolutional layer in Chapter 19: the machinery is fixed in the architecture, and gradient descent chooses the weights.

2. Correlation: Slide, Multiply, Sum Beginner

Let $I$ be a grayscale image and $K$ a kernel of size $(2a+1) \times (2b+1)$, indexed so that $K(0,0)$ is its center. Cross-correlation (usually just "correlation") is defined as:

$$ (I \otimes K)(x, y) \;=\; \sum_{i=-a}^{a} \sum_{j=-b}^{b} K(i, j)\, I(x + i,\; y + j) $$

In words: lay the kernel on the image with its center at $(x, y)$, multiply each kernel weight by the pixel directly underneath it, and add everything up. Figure 3.1.1 traces one stop of this process: the shaded $3 \times 3$ patch of the input aligns with the kernel, their elementwise products are summed, and the single resulting number lands in the output image at the center position.

Implementing this directly is the best way to internalize it. The version below uses two explicit loops over output positions and a vectorized multiply-sum for the window itself, the idiom established in Chapter 0. The input is padded by reflection so the output has the same size as the input; border strategies get a full treatment in Section 3.6.

import numpy as np

def correlate2d(img: np.ndarray, kernel: np.ndarray) -> np.ndarray:
    """Cross-correlation of a 2D grayscale image with a 2D kernel.
    Output has the same shape as the input (reflect padding)."""
    kh, kw = kernel.shape
    ph, pw = kh // 2, kw // 2                      # padding on each side
    padded = np.pad(img.astype(np.float64),
                    ((ph, ph), (pw, pw)), mode="reflect")
    out = np.empty(img.shape, dtype=np.float64)
    for y in range(img.shape[0]):
        for x in range(img.shape[1]):
            window = padded[y:y + kh, x:x + kw]    # the pixels under the kernel
            out[y, x] = np.sum(window * kernel)    # multiply-and-sum
    return out

box = np.full((3, 3), 1.0 / 9.0)                   # 3x3 averaging kernel
img = np.array([[12, 10, 11, 12, 10],
                [90, 95, 88, 92, 91],
                [91, 93, 94, 90, 92],
                [89, 92, 91, 93, 90],
                [90, 91, 92, 90, 91]], dtype=np.float64)
print(correlate2d(img, box)[2, 2])   # average of the central 3x3 block
# Expected output: 92.0  (mean of 95, 88, 92, 93, 94, 90, 92, 91, 93)

This implementation is correct and instructive, and roughly a thousand times slower than production code. Each output pixel costs $k^2$ multiplications and additions, executed through the Python interpreter. Section 3.6 shows where the speed actually comes from; for now the loop's transparency is the point.

3. Convolution: The Flip That Matters Intermediate

True convolution is correlation with the kernel rotated by 180 degrees (flipped both horizontally and vertically):

$$ (I * K)(x, y) \;=\; \sum_{i=-a}^{a} \sum_{j=-b}^{b} K(i, j)\, I(x - i,\; y - j) $$

The only change from correlation is the minus signs: the kernel indices run against the image indices. For any kernel that is symmetric under 180-degree rotation, which includes the box, the Gaussian of Section 3.2, and the Laplacian of Section 3.4, the flip changes nothing and the two operations coincide. So why does the flipped version get the famous name and the asterisk?

The answer is algebra. With the flip, convolution becomes commutative ($I * K = K * I$) and, crucially, associative: $(I * K_1) * K_2 = I * (K_1 * K_2)$. Associativity is a working tool, not a formality. It means you can convolve two small kernels with each other once, offline, and apply the combined kernel in a single pass instead of two. It also underpins the convolution theorem of Chapter 4, which converts convolution into multiplication in the frequency domain. Correlation without the flip satisfies neither property. The flip is the price of good algebra.

The cleanest way to see the difference is the impulse response: filter an image that is all zeros except a single 1. Convolution stamps a copy of the kernel, exactly as written, centered on the impulse. Correlation stamps the kernel flipped. The following experiment makes the distinction concrete with an asymmetric kernel, using SciPy's reference implementations.

import numpy as np
from scipy import ndimage

impulse = np.zeros((5, 5))
impulse[2, 2] = 1.0                       # a single bright pixel

k = np.array([[1., 2., 3.],
              [4., 5., 6.],
              [7., 8., 9.]])              # deliberately asymmetric

conv = ndimage.convolve(impulse, k)       # true convolution (flips k)
corr = ndimage.correlate(impulse, k)      # correlation (no flip)

print(conv[1:4, 1:4])
# [[1. 2. 3.]
#  [4. 5. 6.]
#  [7. 8. 9.]]    <- convolution reproduces the kernel as written
print(corr[1:4, 1:4])
# [[9. 8. 7.]
#  [6. 5. 4.]
#  [3. 2. 1.]]    <- correlation reproduces it rotated 180 degrees

This experiment also demonstrates two properties worth naming. Filtering is linear: the response to a sum of images is the sum of the responses, scaled inputs give scaled outputs. And it is shift-invariant: move the impulse, and the stamped kernel moves with it, unchanged. Together these make filtering a linear shift-invariant (LSI) system, fully characterized by its impulse response. Knowing what a filter does to a single bright pixel tells you what it does to every image, because every image is a sum of scaled, shifted impulses.

4. A Gallery of Kernels Beginner

To build intuition for how weights become behavior, Table 3.1.1 collects five canonical $3 \times 3$ kernels. Each one is a preview of a later section; reading the table now and again at the end of the chapter is a worthwhile exercise in itself.

Two normalization conventions in the table deserve attention because they generalize. Kernels whose weights sum to 1 preserve the average brightness of the image; all smoothing kernels obey this. Kernels whose weights sum to 0 respond only to change, returning zero on constant regions; all derivative kernels obey that. When a hand-designed kernel misbehaves, the weight sum is the first thing to check.

5. The Same Operation in OpenCV and PyTorch Intermediate

In production code, nobody writes the double loop. OpenCV's cv2.filter2D applies an arbitrary kernel to an image with SIMD vectorization, multithreading, and automatic switchover to a frequency-domain algorithm for large kernels. One subtlety hides in the documentation: filter2D computes correlation, not convolution. For a true convolution you must flip the kernel yourself, exactly as the impulse experiment above would reveal.

import cv2
import numpy as np

img = cv2.imread("street.jpg", cv2.IMREAD_GRAYSCALE)

sharpen = np.array([[ 0, -1,  0],
                    [-1,  5, -1],
                    [ 0, -1,  0]], dtype=np.float32)

# cv2.filter2D computes CORRELATION with the given kernel.
out_corr = cv2.filter2D(img, ddepth=-1, kernel=sharpen)

# For true convolution, flip the kernel 180 degrees first.
out_conv = cv2.filter2D(img, ddepth=-1, kernel=cv2.flip(sharpen, -1))

# For this symmetric kernel the two are identical:
print(np.array_equal(out_corr, out_conv))   # True

The PyTorch version of the same operation matters enormously for this book, because it is the bridge to Part III. torch.nn.functional.conv2d expects tensors shaped (batch, channels, height, width) and, as the fun fact above warned, computes cross-correlation despite the name. The code below applies our Sobel kernel from Table 3.1.1 and verifies the flip relationship numerically.

import torch
import torch.nn.functional as F

x = torch.rand(1, 1, 64, 64)                  # (batch, channels, H, W)

sobel = torch.tensor([[[[-1., 0., 1.],
                        [-2., 0., 2.],
                        [-1., 0., 1.]]]])     # (out_ch, in_ch, kH, kW)

# F.conv2d computes cross-correlation (no flip), like cv2.filter2D.
corr = F.conv2d(x, sobel, padding=1)

# True convolution = correlate with the kernel flipped in both
# spatial dimensions (dims 2 and 3 of the weight tensor).
conv = F.conv2d(x, torch.flip(sobel, dims=[2, 3]), padding=1)

print(torch.allclose(corr, -conv))   # True: flipping Sobel negates it

Read that weight shape (out_channels, in_channels, kH, kW) carefully, because it quietly contains the whole design of a CNN layer: a stack of many kernels (out_channels of them), each spanning all input channels, applied by exactly the machinery of this section. When Chapter 19 swaps our hand-written Sobel values for requires_grad=True parameters, nothing else changes. And when Chapter 33 builds the U-Net that powers diffusion models, it is this same call, repeated a few hundred times.

6. What Shift Invariance Buys, and What It Costs Intermediate

Shift invariance, the property that the kernel applies the same weights at every location, is both filtering's superpower and its built-in limitation. The superpower: one small set of weights serves the whole image, which is why a $3 \times 3$ kernel with 9 numbers can process a 12-megapixel photograph, and why CNNs need so many fewer parameters than fully connected networks. A pattern detector that works in the top-left corner works identically everywhere, matching the physics of photography: objects do not change identity by moving across the frame.

The cost: a shift-invariant filter cannot adapt to content. It smooths edges exactly as enthusiastically as it smooths noise, a tension that dominates Section 3.2 and is only resolved in Section 3.5 by filters whose weights depend on local pixel values, deliberately breaking shift invariance. Keep this tradeoff in mind as a running theme: most of the chapter's intellectual drama is the struggle between uniform processing and content adaptation.
