Incremental Structure from Motion

"Choose your first two friends carefully. Everyone who joins the party afterwards will be positioned, for all eternity, relative to them."

An Incremental Mapper With Strong Opinions About Seating

With tracks in hand, the reconstruction problem becomes concrete: estimate a rotation $R_i$ and translation $\mathbf{t}_i$ for every image and a 3D position $\mathbf{X}_j$ for every track, such that each track's observations land where the cameras say they should. Solving for everything at once from scratch is possible (global SfM, which we will meet at the end of this section), but the workhorse strategy of the last two decades is incremental: establish a small, high-quality core, then expand it one camera at a time. The order of operations matters enormously, and the algorithm's intelligence lives mostly in its choices of what to add next and what to throw away.

1. The Two-View Seed Intermediate

Everything starts from one image pair, and the choice is consequential because the seed defines the coordinate frame and the (arbitrary) global scale that every later camera inherits. A good seed pair has three properties. First, many verified inliers, so the relative pose is reliable. Second, a wide baseline: a large triangulation angle between the viewing rays makes the initial points accurate, whereas a narrow baseline puts every point's depth in doubt, exactly the quadratic depth-error effect quantified in Chapter 13. Third, the pair must not be homography-dominated: if a single plane or a pure rotation explains the matches, as flagged on the match-graph edges of Section 14.1, the pair carries almost no parallax and triangulating from it builds the whole model on sand. COLMAP scores candidate seeds by exactly these criteria.

Once chosen, the seed reconstruction is pure Chapter 13: essential matrix, pose recovery, triangulation, plus the quality filters that incremental SfM applies relentlessly from the first moment. The listing below bootstraps a map from images 0 and 1, keeping only points that are in front of both cameras, triangulated with a sufficient ray angle, and consistent with their observations.

import cv2
import numpy as np

def reproj_error(P, X, x):
    """Pixel distance between projection of 3D points X and observations x."""
    Xh = np.hstack([X, np.ones((len(X), 1))])
    proj = (P @ Xh.T).T
    proj = proj[:, :2] / proj[:, 2:]
    return np.linalg.norm(proj - x, axis=1)

# p0, p1: Nx2 float32 arrays of verified matches between images 0 and 1
E, _ = cv2.findEssentialMat(p0, p1, cameraMatrix=K,
                            method=cv2.USAC_MAGSAC, threshold=1.5)
n_inl, R, t, mask = cv2.recoverPose(E, p0, p1, K)     # cheirality check inside
keep = mask.ravel().astype(bool)

P0 = K @ np.hstack([np.eye(3), np.zeros((3, 1))])     # camera 0 = world origin
P1 = K @ np.hstack([R, t])                            # |t| = 1: scale is arbitrary
Xh = cv2.triangulatePoints(P0, P1, p0[keep].T, p1[keep].T)
X = (Xh[:3] / Xh[3]).T                                # Nx3 points, world frame

# quality gates: ray angle and reprojection error
rays0 = X / np.linalg.norm(X, axis=1, keepdims=True)
C1 = (-R.T @ t).ravel()                               # center of camera 1
rays1 = X - C1
rays1 /= np.linalg.norm(rays1, axis=1, keepdims=True)
angles = np.degrees(np.arccos(np.clip((rays0 * rays1).sum(1), -1, 1)))
err = np.maximum(reproj_error(P0, X, p0[keep]), reproj_error(P1, X, p1[keep]))
good = (angles > 2.0) & (err < 2.0) & (X[:, 2] > 0)

print(f"seed: {good.sum()} points kept of {len(X)} "
      f"(median angle {np.median(angles):.1f} deg, median err {np.median(err):.2f}px)")
# seed: 1376 points kept of 1671 (median angle 7.4 deg, median err 0.41px)

Two details deserve emphasis. The translation from recoverPose has unit norm: monocular reconstruction has no access to metric scale, so the seed baseline defines the map unit, a gauge freedom we will meet formally in Section 14.3. And the angle gate is not cosmetic: a point triangulated from rays 0.5 degrees apart can move tens of map units along the ray while changing its reprojection by less than a pixel, so admitting it pollutes the map with pseudo-structure that later PnP steps will trust to their detriment.

2. Registering the Next Camera: PnP Intermediate

Here is the move that makes incremental SfM work. Once the seed map exists, some unregistered images observe tracks that already have 3D positions. For such an image we know a set of 2D-3D correspondences: keypoint $\mathbf{x}_k$ in the new image belongs to a track whose point $\mathbf{X}_k$ is already triangulated. Estimating a camera's pose from $n$ such correspondences, given intrinsics $K$ from Chapter 12, is the Perspective-n-Point problem: find $R$, $\mathbf{t}$ minimizing

$$ \sum_{k=1}^{n} \left\lVert \pi\!\left(K \left[ R \,|\, \mathbf{t} \right] \tilde{\mathbf{X}}_k\right) - \mathbf{x}_k \right\rVert^2 , $$

where $\pi$ is the perspective division. The minimal case $n = 3$ (P3P) has up to four algebraic solutions and is the engine inside RANSAC; larger $n$ is solved by EPnP or SQPnP and refined iteratively. Because some 2D-3D correspondences are wrong (contaminated tracks from Section 14.1, or map points that drifted), registration is always RANSAC-wrapped, just as every estimator has been since Chapter 10:

# X_map: Mx3 triangulated points visible in the new image (via track lookup)
# x_new: Mx2 corresponding keypoint locations in the new image
ok, rvec, tvec, inliers = cv2.solvePnPRansac(
    X_map, x_new, K, distCoeffs=None,
    reprojectionError=4.0,           # pixel tolerance for an inlier vote
    iterationsCount=5000,
    confidence=0.999,
    flags=cv2.SOLVEPNP_EPNP)         # minimal/efficient solver inside RANSAC

assert ok and len(inliers) > 50      # refuse weakly-supported registrations
R_new, _ = cv2.Rodrigues(rvec)       # axis-angle to 3x3 rotation
print(f"registered with {len(inliers)}/{len(X_map)} PnP inliers")
# registered with 412/588 PnP inliers

# refine on inliers only, Levenberg-Marquardt on reprojection error
rvec, tvec = cv2.solvePnPRefineLM(X_map[inliers.ravel()],
                                  x_new[inliers.ravel()], K, None, rvec, tvec)

Which image should be registered next? Greedy intuition says the one seeing the most triangulated points, but COLMAP's next-best-view scoring refines this: it prefers images whose visible map points are spatially well distributed across the frame, because fifty correspondences concentrated in one corner constrain pose far worse than fifty spread evenly. Poor next-view choices were a chief cause of pre-2016 SfM failures: register a barely-connected image early, and its noisy pose seeds bad triangulations that cascade.

3. Growing Structure and the Audit Loop Intermediate

A newly registered camera does two things. It adds observations to existing points (its inlier correspondences extend their tracks), and it makes new triangulations possible: every track observed by the new camera and at least one other registered camera, but not yet triangulated, is now a candidate 3D point, gated by the same angle and reprojection filters as the seed. Then comes the step that separates a working mapper from a toy: the audit. After each registration (or each few), the mapper re-examines the model: observations whose reprojection error has crept above threshold are removed from their tracks; points left with fewer than two observations, or with degenerate angles, are deleted; previously failed triangulations are retried now that more views exist (re-triangulation); and a local bundle adjustment refines the most recently touched cameras and points. Figure 14.2.1 lays out the full cycle.

4. Failure Modes: Drift, Degeneracy, and Doppelgangers Advanced

Incremental SfM inherits three systematic weaknesses worth knowing before you trust its output. Drift: errors compound along the registration order, so a long chain of cameras (a street captured end to end) slowly bends; the reconstruction is locally crisp but globally warped. Only closing a loop in the capture, or external constraints like GPS, can anchor long chains, a theme that returns with full force in the SLAM setting of Section 14.4. Degenerate motion: a segment of near-pure rotation provides no baseline, so nothing new can be triangulated and registration eventually starves; this is the capture-time failure that no algorithm fixes after the fact. Doppelgangers: the repeated-structure merges of Section 14.1, which at reconstruction time manifest as a camera confidently registered to the wrong instance of a repeated facade. The audit loop catches many; the rest require the graph-level priors discussed there.

5. Incremental versus Global SfM Advanced

The incremental strategy is not the only one. Global SfM estimates all camera rotations at once by averaging the pairwise relative rotations on the match graph (rotation averaging), then solves all translations and triangulates everything in a second pass, finishing with one global bundle adjustment. It is dramatically faster, since there are no thousands of intermediate local adjustments, and free of registration-order drift; historically it was also far more brittle, because a few bad edges in the match graph could corrupt the averaged solution where the incremental audit loop would have caught them. That trade-off was substantially rebalanced in 2024: GLOMAP, from the COLMAP lineage, made global SfM robust enough to match incremental quality on standard benchmarks at one to two orders of magnitude less compute, mainly by skipping the fragile separate translation-averaging step and solving camera positions and 3D structure jointly. For very large, well-connected collections, global methods are now often the default; incremental mapping retains the edge on sparse, weakly connected, or sequentially captured sets where its caution pays.
