Visualizing What CNNs Learn

"You trained me, and now you want to know what I am thinking. Fair. Layer one learned edges, which you could have told me. Layer twelve learned something it refuses to name, and a heatmap is the closest you will get to an answer."

A Trained but Mysterious Convolutional Network

You have built, trained, and tested a convolutional network; this closing section asks what it learned. Interpretability is not idle curiosity. Visualizing a CNN catches the failure in the plant-disease story of Section 19.5 (a model keying on background instead of lesions), validates that the network attends to sensible evidence before you deploy it, and closes the chapter's signature arc by showing that learnable convolution rediscovers the hand-designed filters of Part I. We work through four techniques in increasing sophistication, from simply plotting the weights to attributing a prediction to input pixels.

1. First-Layer Filters: Convolution Rediscovers the Sobel Kernel Beginner

The first convolutional layer's weights are directly viewable as images, because each filter is a small grid that operates on the raw input channels. A filter that spans the three input channels of a color image forms a small color patch (a $3 \times 3$ patch for a $3 \times 3$ kernel, a $7 \times 7$ patch for the $7 \times 7$ first kernel of ResNet-18 used below). The remarkable, reliably reproduced result, first shown clearly by Zeiler and Fergus and visible in essentially every trained vision network from AlexNet onward, is that these learned filters look like oriented edge detectors, color-opponent patches, and small frequency gratings. They are, to the eye, the Sobel kernels you constructed by hand in Chapter 3, the oriented Gabor filters of Section 4.6, and the gradient operators of Chapter 9. Gradient descent, given only a classification loss, reinvents the edge detector because it is the most useful local primitive, exactly as Section 19.3 predicted. The code below extracts and normalizes the first-layer weights for display.

import torch
import torchvision

# A pretrained network has cleaner, more interpretable filters than a 30-epoch CIFAR net.
model = torchvision.models.resnet18(weights="IMAGENET1K_V1").eval()

# The first conv is 64 filters, each 3x7x7 (3 input channels, 7x7 spatial kernel in resnet18).
w = model.conv1.weight.data.clone()        # shape: (64, 3, 7, 7)
print(w.shape)                             # torch.Size([64, 3, 7, 7])

# Normalize each filter to [0, 1] so it can be shown as an RGB image.
w_min = w.amin(dim=(1, 2, 3), keepdim=True)
w_max = w.amax(dim=(1, 2, 3), keepdim=True)
grid_filters = (w - w_min) / (w_max - w_min + 1e-8)   # (64, 3, 7, 7) in [0,1]

# Lay the 64 filters out in an 8x8 grid for a single displayable image.
grid = torchvision.utils.make_grid(grid_filters, nrow=8, padding=1)
print(grid.shape)        # torch.Size([3, 65, 65]) -> save with torchvision or plt.imshow
# torchvision.utils.save_image(grid, "conv1_filters.png")

Fun Note: Gradient Descent Reinvents the Wheel, On Purpose

There is something quietly hilarious about it. You spent Chapter 3 hand-crafting Sobel kernels and Section 4.6 building Gabor filters, and a network that was never told edges exist, never shown your kernels, optimizing only "guess the label," walks up and learns the same filters anyway. It is the universe confirming your homework. The takeaway is not "we wasted Chapter 3"; it is the opposite: the edge detector is not an arbitrary choice, it is what falls out when you ask any visual system to be useful. Designed or learned, the first layer always rediscovers the edge. The illustration below stages exactly that coincidence.

2. Feature Maps: What a Layer Responds To Beginner

Past the first layer, the filters operate on abstract features and are no longer directly viewable as images. Instead we inspect feature maps: the activations a specific input produces at a given layer. PyTorch's forward hooks let you capture any layer's output without modifying the model. Feeding an image and visualizing a deep layer's channels shows that some respond to textures, some to specific parts, and many to nothing for this particular image (a sparse response is normal). The code below registers a hook and captures one intermediate activation.

import torch

activations = {}
def save_hook(name):
    def hook(module, inp, out):
        activations[name] = out.detach()   # store the layer's output for this input
    return hook

# Register a hook on a mid-depth layer of the pretrained ResNet-18.
handle = model.layer2.register_forward_hook(save_hook("layer2"))

x = torch.randn(1, 3, 224, 224)            # stand-in for a normalized input image
_ = model(x)                               # forward pass triggers the hook
handle.remove()                            # always remove hooks when done

fmap = activations["layer2"]               # captured activations
print(fmap.shape)                          # torch.Size([1, 128, 28, 28]) -> 128 feature maps
# Each of the 128 channels is a 28x28 map; plot a few with plt.imshow(fmap[0, c].cpu()).

A complementary technique is to find the maximally activating patches: run many images through the network and, for a chosen channel, collect the input patches (cropped to that neuron's receptive field from Section 19.3) that produced the strongest activations. The collected patches form a visual definition of what the neuron detects, often strikingly coherent (a "dog face" neuron, a "wheel" neuron), and this is how researchers map the feature hierarchy in practice.

3. Saliency Maps: Which Pixels Mattered Intermediate

The previous lenses describe the network in general; saliency maps explain one specific prediction. The simplest version, vanilla gradient saliency, asks: how much does each input pixel affect the score for the predicted class? That is exactly the gradient of the class score with respect to the input, computed by backpropagation but to the image rather than to the weights. Pixels with large gradient magnitude are the ones a small change to which would most move the prediction, so they are the evidence the network used. Formally, for class score $s_c$ and input image $I$, the saliency at pixel $(x, y)$ is:

$$ M(x, y) \;=\; \max_{\text{channel } k} \left| \frac{\partial s_c}{\partial I_{k, x, y}} \right|. $$

The code below computes a saliency map by enabling gradients on the input and backpropagating the top class score.

import torch

model.eval()
x = torch.randn(1, 3, 224, 224, requires_grad=True)   # gradients flow to the input

scores = model(x)                       # (1, 1000) class logits
top_class = scores.argmax(dim=1)        # the predicted class
score = scores[0, top_class]            # the scalar score we explain

model.zero_grad()
score.backward()                        # d(score)/d(input) lands in x.grad

# Saliency: max absolute gradient across color channels, per pixel.
saliency = x.grad.abs().amax(dim=1)     # shape: (1, 224, 224)
print(saliency.shape)                   # torch.Size([1, 224, 224])
# Bright regions in saliency mark the pixels that most influenced the prediction;
# plot with plt.imshow(saliency[0].cpu(), cmap="hot").

4. Grad-CAM: Class-Discriminative Evidence Intermediate

Vanilla saliency is noisy and not very class-specific. Grad-CAM (Gradient-weighted Class Activation Mapping) gives a cleaner, class-discriminative answer by working at the last convolutional layer, where the feature maps are still spatial but already semantic. It computes how important each feature-map channel is to the target class (by averaging the gradient of the class score over that channel's spatial positions), takes a weighted sum of the feature maps with those importances, and keeps only the positive part. The result is a coarse heatmap, at the resolution of the last conv layer, that localizes the image region driving the prediction. Writing $A^k$ for the $k$-th feature map of the chosen layer, $\alpha_k^c$ for its importance to class $c$, and $Z$ for the number of spatial positions in the map (so the sum over $i, j$ is just an average gradient):

$$ \alpha_k^c = \frac{1}{Z}\sum_{i,j} \frac{\partial s_c}{\partial A^k_{ij}}, \qquad L^c_{\text{Grad-CAM}} = \mathrm{ReLU}\!\left( \sum_k \alpha_k^c\, A^k \right). $$

Grad-CAM is the standard production tool for "why did the model say that?", because it works on any CNN without retraining, is class-specific (you can ask why it said "cat" even when it predicted "dog"), and overlays cleanly on the input. Figure 19.6.2 sketches how Grad-CAM combines a layer's feature maps into a class heatmap.

This closes Chapter 19. You can now derive the convolutional layer from first principles, configure it with channels, stride, padding, and dilation, reason about its receptive field and feature hierarchy, stabilize a deep stack with normalization, train a complete network end to end, and open the trained model to see what it learned. The chapter's arc, from the hand-designed kernels of Chapter 3 to filters that rediscover them, is complete. The hands-on lab below pulls every thread of the chapter into one artifact you build and run; after it, Chapter 20 takes the conv-BN-ReLU block you assembled here and shows the great architectures built from it, from LeNet to ResNet to ConvNeXt, and the design decisions that separate a good network from a state-of-the-art one.

pip install torch torchvision matplotlib

import torch, torch.nn as nn, torchvision, torchvision.transforms as T

device = "cuda" if torch.cuda.is_available() else "cpu"

# TODO: paste conv_block and SmallCNN from Section 19.5, then train for ~20 epochs.
# Hint: the only outputs this lab needs are the trained `model` (in eval mode)
#       and a `test_loader` over un-normalized-friendly CIFAR-10 test images.
model = ...        # trained SmallCNN().to(device)
model.eval()

import torchvision.transforms.functional as TF

CLASSES = ["plane","car","bird","cat","deer","dog","frog","horse","ship","truck"]
img, label = next(iter(test_loader))          # take a batch
x = img[0:1].to(device)                        # keep batch dim: shape (1, 3, 32, 32)

# TODO: run the model on x, confirm the prediction matches label[0],
#       and store the predicted class index in `pred`.
pred = ...
print("true:", CLASSES[label[0]], "| pred:", CLASSES[pred])

# TODO: grab the first conv layer's weight tensor (shape: out_ch, 3, 3, 3),
#       normalize each filter to [0, 1] for display, and build a tile grid.
first_conv = ...           # the first nn.Conv2d module in the model
W = first_conv.weight.detach().cpu()
# Hint: per-filter min-max normalize, then torchvision.utils.make_grid(W, nrow=8)
filter_grid = ...

activation = {}
def hook(module, inp, out):
    activation["feat"] = out.detach()

# TODO: register the hook on a middle conv layer, run the forward pass again,
#       then select one channel of activation["feat"][0] to display.
handle = ...               # target_layer.register_forward_hook(hook)
_ = model(x)
handle.remove()
feat_channel = ...         # e.g. activation["feat"][0, 0].cpu()

x_in = x.clone().requires_grad_(True)
score = model(x_in)[0, pred]
# TODO: backprop `score`, then reduce x_in.grad over the color channels
#       (max of absolute value) to a single-channel saliency map.
score.backward()
saliency = ...             # shape (32, 32)

# TODO: capture the last conv layer's activations AND their gradients,
#       compute channel weights = global-average-pooled gradients,
#       form cam = ReLU(sum_c weight_c * activation_c), upsample to 32x32.
cam = ...                  # shape (32, 32), normalized to [0, 1]

import matplotlib.pyplot as plt
# TODO: build a 2x3 grid of subplots: input, first-layer filters, feature map,
#       saliency overlay, Grad-CAM overlay. Add a suptitle with true/pred labels.
#       Save with plt.savefig("cnn_report_card.png", dpi=150, bbox_inches="tight").

import torch, torch.nn as nn, torch.nn.functional as F
import torchvision, torchvision.transforms as T
from torchvision.utils import make_grid
import matplotlib.pyplot as plt

device = "cuda" if torch.cuda.is_available() else "cpu"
MEAN = (0.4914, 0.4822, 0.4465); STD = (0.2470, 0.2435, 0.2616)
CLASSES = ["plane","car","bird","cat","deer","dog","frog","horse","ship","truck"]

# ---- Step 1: network (conv-BN-ReLU block + SmallCNN) and a short training run ----
def conv_block(in_ch, out_ch, stride=1):
    return nn.Sequential(
        nn.Conv2d(in_ch, out_ch, 3, stride=stride, padding=1, bias=False),
        nn.BatchNorm2d(out_ch), nn.ReLU(inplace=True))

class SmallCNN(nn.Module):
    def __init__(self, n=10):
        super().__init__()
        self.features = nn.Sequential(
            conv_block(3, 32),  conv_block(32, 32, stride=2),    # 32x32 -> 16x16
            conv_block(32, 64), conv_block(64, 64, stride=2),    # 16x16 -> 8x8
            conv_block(64,128), conv_block(128,128, stride=2))   # 8x8 -> 4x4
        self.head = nn.Linear(128, n)
    def forward(self, x):
        x = self.features(x)
        x = F.adaptive_avg_pool2d(x, 1).flatten(1)               # global average pool
        return self.head(x)

train_tf = T.Compose([T.RandomCrop(32, padding=4), T.RandomHorizontalFlip(),
                      T.ToTensor(), T.Normalize(MEAN, STD)])
test_tf  = T.Compose([T.ToTensor(), T.Normalize(MEAN, STD)])
train_set = torchvision.datasets.CIFAR10("./data", train=True,  download=True, transform=train_tf)
test_set  = torchvision.datasets.CIFAR10("./data", train=False, download=True, transform=test_tf)
train_loader = torch.utils.data.DataLoader(train_set, 128, shuffle=True,  num_workers=2)
test_loader  = torch.utils.data.DataLoader(test_set,  256, shuffle=False, num_workers=2)

model = SmallCNN().to(device)
opt = torch.optim.SGD(model.parameters(), lr=0.1, momentum=0.9, weight_decay=5e-4)
EPOCHS = 20
sched = torch.optim.lr_scheduler.CosineAnnealingLR(opt, EPOCHS)
for epoch in range(EPOCHS):
    model.train()
    for xb, yb in train_loader:
        xb, yb = xb.to(device), yb.to(device)
        opt.zero_grad()
        F.cross_entropy(model(xb), yb).backward()
        opt.step()
    sched.step()
model.eval()

# ---- Step 2: pick one correctly classified image ----
imgs, labels = next(iter(test_loader))
idx = 0
for i in range(imgs.size(0)):
    xi = imgs[i:i+1].to(device)
    if model(xi).argmax(1).item() == labels[i].item():
        idx = i; break
x = imgs[idx:idx+1].to(device)
label = labels[idx].item()
pred  = model(x).argmax(1).item()
print("true:", CLASSES[label], "| pred:", CLASSES[pred])

def denorm(t):  # invert normalization for display, returns HxWx3 in [0,1]
    t = t.detach().cpu()[0].clone()
    for c in range(3): t[c] = t[c]*STD[c] + MEAN[c]
    return t.clamp(0,1).permute(1,2,0).numpy()

# ---- Step 3: first-layer filters ----
first_conv = next(m for m in model.modules() if isinstance(m, nn.Conv2d))
W = first_conv.weight.detach().cpu()
W = (W - W.amin((1,2,3),keepdim=True)) / (W.amax((1,2,3),keepdim=True) - W.amin((1,2,3),keepdim=True) + 1e-8)
filter_grid = make_grid(W, nrow=8, padding=1).permute(1,2,0).numpy()

# ---- Step 4: a mid-network feature map ----
convs = [m for m in model.modules() if isinstance(m, nn.Conv2d)]
mid_layer  = convs[len(convs)//2]
last_conv  = convs[-1]
acts, grads = {}, {}
h1 = mid_layer.register_forward_hook(lambda m,i,o: acts.__setitem__("mid", o.detach()))
h2 = last_conv.register_forward_hook(lambda m,i,o: acts.__setitem__("last", o))
h3 = last_conv.register_full_backward_hook(lambda m,gi,go: grads.__setitem__("last", go[0].detach()))

# ---- Step 5 + 6: saliency and Grad-CAM in one forward/backward ----
x_in = x.clone().requires_grad_(True)
logits = model(x_in)
score = logits[0, pred]
model.zero_grad(); score.backward()
saliency = x_in.grad.abs()[0].amax(0).cpu()
saliency = (saliency - saliency.min()) / (saliency.max() - saliency.min() + 1e-8)
feat_channel = acts["mid"][0].mean(0).cpu()                      # averaged feature map
weights = grads["last"].mean((2,3), keepdim=True)               # global-average-pooled grads
cam = (weights * acts["last"]).sum(1).relu()[0]                 # ReLU(weighted sum)
cam = F.interpolate(cam[None,None], size=(32,32), mode="bilinear", align_corners=False)[0,0]
cam = (cam - cam.min()) / (cam.max() - cam.min() + 1e-8)
cam = cam.detach().cpu()
for h in (h1, h2, h3): h.remove()

# ---- Step 7: compose and save the report card ----
rgb = denorm(x)
fig, ax = plt.subplots(2, 3, figsize=(11, 7))
ax[0,0].imshow(rgb);                         ax[0,0].set_title("input")
ax[0,1].imshow(filter_grid);                 ax[0,1].set_title("first-layer filters")
ax[0,2].imshow(feat_channel, cmap="viridis");ax[0,2].set_title("mid feature map")
ax[1,0].imshow(saliency, cmap="hot");        ax[1,0].set_title("saliency")
ax[1,1].imshow(rgb); ax[1,1].imshow(saliency, cmap="jet", alpha=0.5); ax[1,1].set_title("saliency overlay")
ax[1,2].imshow(rgb); ax[1,2].imshow(cam, cmap="jet", alpha=0.5);      ax[1,2].set_title("Grad-CAM")
for a in ax.ravel(): a.axis("off")
fig.suptitle(f"CNN report card  |  true: {CLASSES[label]}   pred: {CLASSES[pred]}", fontsize=13)
plt.tight_layout()
plt.savefig("cnn_report_card.png", dpi=150, bbox_inches="tight")
print("saved cnn_report_card.png")
