The Detection Problem: Boxes, IoU & mAP

"They asked me how good my boxes were. I said most of them are pretty close. That, it turns out, is not a number. So they invented one, then another to average the first, then a third to average that. Now my report card is a single decimal and I lie awake worrying about the second digit."

A Detector Anxious About Its Average Precision

In the previous chapters a network mapped an image to one decision. A classifier sees a photo and returns "cat"; a Vision Transformer from Chapter 22 sees a photo and returns "cat" with a probability. Object detection asks for much more. Given the same photo, a detector must return a list: a cat at pixels (x1, y1, x2, y2) with confidence 0.94, a sofa at (x3, y3, x4, y4) with confidence 0.81, and so on, with the length of that list depending on what is actually in the image. The output is a set of localized, classified, scored predictions, and the number of elements is not known in advance. Everything difficult about detection flows from that one fact, and so does everything in this section, because before we can build a model that emits such a set we must agree on how to grade it (the illustration below contrasts the two jobs).

1. What a Detector Outputs Beginner

A single detection is a tuple: a class label, a confidence score in $[0, 1]$, and a bounding box. The box is the geometric heart of detection, so fix its conventions now to avoid the off-by-one and format confusions that cause more detector bugs than any algorithm. The two dominant formats are corner format, written $(x_{\min}, y_{\min}, x_{\max}, y_{\max})$, the pixel coordinates of the top-left and bottom-right corners, and center format, written $(c_x, c_y, w, h)$, the center coordinate plus width and height. torchvision and COCO use corner format; YOLO predicts and stores center format (often normalized to $[0, 1]$ by the image size). Converting between them is trivial but must be done consistently, and a great many "the model trained but predicts nonsense" reports trace to a silent format mismatch.

Image coordinates put the origin at the top-left, $x$ increasing to the right and $y$ increasing downward, the same convention you have used since Chapter 1. Figure 23.1.1 shows the two formats on one box and names the quantities we will use throughout the chapter.

The code below defines the conversions we will reuse. Run it against the figure: a box whose corners are $(120, 100)$ and $(280, 210)$ has center $(200, 155)$, width $160$, and height $110$.

# Convert bounding boxes between the two conventions used in detection:
# corner format (x_min, y_min, x_max, y_max) and center format (cx, cy, w, h).
# The conversions are exact inverses, which gives us a free round-trip test.
import numpy as np

def corner_to_center(box):
    """(x_min, y_min, x_max, y_max) -> (cx, cy, w, h)."""
    x1, y1, x2, y2 = box
    return np.array([(x1 + x2) / 2, (y1 + y2) / 2, x2 - x1, y2 - y1])

def center_to_corner(box):
    """(cx, cy, w, h) -> (x_min, y_min, x_max, y_max)."""
    cx, cy, w, h = box
    return np.array([cx - w / 2, cy - h / 2, cx + w / 2, cy + h / 2])

b = np.array([120, 100, 280, 210])          # corner format
print(corner_to_center(b))                  # [200. 155. 160. 110.]
print(center_to_corner(corner_to_center(b)))# [120. 100. 280. 210.] round-trips

2. Intersection over Union: Scoring One Box Beginner

A predicted box almost never matches a ground-truth box exactly, so we need a continuous measure of how well they overlap. The standard is intersection over union (IoU), also called the Jaccard index: the area of the overlap of two boxes divided by the area of their union.

IoU is $0$ when the boxes are disjoint, $1$ when they coincide exactly, and somewhere in between otherwise. It is invariant to the overall scale of the image and it penalizes both a box that is too large (extra union) and one that is too small (missing intersection), which is exactly why it became the universal currency of detection. A detection is conventionally counted as correct when its IoU with a ground-truth box of the same class exceeds a threshold, classically $0.5$. Figure 23.1.2 shows the geometry: the intersection rectangle is found by taking the larger of the two left edges, the larger of the two top edges, the smaller of the two right edges, and the smaller of the two bottom edges.

The implementation follows the figure line for line, and it is worth getting exactly right because every matching decision and every loss in the chapter calls it. Notice the max(0, ...) clamp: when the boxes do not overlap, the naive intersection width or height goes negative, and without the clamp you would compute a spurious positive area.

def iou(box_a, box_b):
    """IoU of two corner-format boxes (x_min, y_min, x_max, y_max)."""
    # Intersection rectangle: inner edges of the two boxes.
    x1 = max(box_a[0], box_b[0])
    y1 = max(box_a[1], box_b[1])
    x2 = min(box_a[2], box_b[2])
    y2 = min(box_a[3], box_b[3])
    inter = max(0.0, x2 - x1) * max(0.0, y2 - y1)   # clamp handles no-overlap
    area_a = (box_a[2] - box_a[0]) * (box_a[3] - box_a[1])
    area_b = (box_b[2] - box_b[0]) * (box_b[3] - box_b[1])
    union = area_a + area_b - inter
    return inter / union if union > 0 else 0.0

A = [60, 60, 260, 210]      # ground truth
B = [170, 110, 370, 260]    # prediction
print(round(iou(A, B), 3))  # 0.176
print(round(iou(A, A), 3))  # 1.0  (a box overlaps itself perfectly)

3. Precision, Recall, and the Matching Rule Intermediate

With IoU in hand we can classify each prediction. For a single class and a single image, sort the predictions by confidence, then walk down that list assigning each prediction to the highest-IoU unassigned ground-truth box of the same class. A prediction is a true positive (TP) if its best match has IoU above the threshold and that ground-truth box has not already been claimed by a higher-confidence prediction; otherwise it is a false positive (FP). Any ground-truth box left unclaimed at the end is a false negative (FN), a missed object. The "already claimed" rule is what punishes duplicate boxes: if a detector fires three nearly identical boxes on one object, only the most confident one is a TP and the other two are FPs.

From these counts come the two quantities you balance for the rest of your detection career. Precision is the fraction of predictions that were correct, $\text{TP} / (\text{TP} + \text{FP})$: how much you can trust a box the model emits. Recall is the fraction of ground-truth objects that were found, $\text{TP} / (\text{TP} + \text{FN})$: how little the model misses. They trade off against each other through the confidence threshold. Lower the threshold and you emit more boxes, finding more objects (higher recall) but admitting more junk (lower precision); raise it and the reverse happens. A single (precision, recall) pair therefore describes only one operating point, which is why no serious detector is summarized by one number at one threshold.

4. Average Precision: Collapsing the Curve Intermediate

Sweep the confidence threshold from high to low and at each setting you get a (recall, precision) point; together they trace the precision-recall curve. A good detector stays high and to the right: high precision maintained even as recall grows. Average precision (AP) for a class is the area under that curve, a single number in $[0, 1]$ that summarizes performance across all thresholds at once. Equivalently, AP is the precision averaged over all recall levels.

The mechanics are: rank every prediction for the class across the whole dataset by descending confidence, walk down the ranking accumulating TP and FP counts, and at each step record the running precision and recall. Because raw precision-recall curves are jagged (precision can briefly rise as recall increases), the COCO protocol applies a monotone envelope first, replacing precision at each recall with the maximum precision at that recall or any higher recall, and then integrates.

Why is the raw curve jagged in the first place? The cause is simple: as you walk down the ranking, each false positive drops precision, but the next true positive both raises recall and nudges precision back up, so the curve zig-zags downward rather than falling smoothly. The envelope simply ignores those upward wiggles by carrying each peak leftward, which makes AP depend only on the best precision achievable at each recall level. The formula for the interpolated AP is

where $p(r)$ is the measured precision at recall $r$. Figure 23.1.3 shows a jagged curve and the staircase envelope whose area is AP.

The function below computes AP for one class from a list of (confidence, is_true_positive) pairs and the total count of ground-truth objects. It implements the rank-accumulate-interpolate-integrate recipe directly so you can see every step.

def average_precision(detections, n_ground_truth):
    """detections: list of (confidence, is_tp) for one class, across the dataset.
       n_ground_truth: total number of GT boxes of this class."""
    if n_ground_truth == 0:
        return 0.0
    # 1. Rank by descending confidence.
    detections = sorted(detections, key=lambda d: -d[0])
    tp = fp = 0
    precisions, recalls = [], []
    for _, is_tp in detections:
        tp += int(is_tp)
        fp += int(not is_tp)
        precisions.append(tp / (tp + fp))
        recalls.append(tp / n_ground_truth)
    # 2. Monotone envelope: precision is made non-increasing in recall (from the right).
    for i in range(len(precisions) - 2, -1, -1):
        precisions[i] = max(precisions[i], precisions[i + 1])
    # 3. Integrate precision over recall (sum of rectangles between recall steps).
    ap, prev_recall = 0.0, 0.0
    for p, r in zip(precisions, recalls):
        ap += p * (r - prev_recall)
        prev_recall = r
    return ap

dets = [(0.95, 1), (0.91, 1), (0.88, 0), (0.80, 1), (0.74, 0), (0.65, 1)]
print(round(average_precision(dets, n_ground_truth=4), 3))   # 1.0

5. Mean Average Precision and the COCO Protocol Intermediate

Mean average precision (mAP) is simply the AP averaged over all classes. That is the headline number every detector reports, but the details of how it is computed matter enormously when you compare papers, so pin them down. The older PASCAL VOC protocol (see the classical recognition pipelines of Chapter 16 for the lineage) computes AP at a single IoU threshold of $0.50$ and means over the 20 VOC classes. The modern COCO protocol is stricter and is the one you will see almost everywhere today: it computes AP at ten IoU thresholds from $0.50$ to $0.95$ in steps of $0.05$ and averages those too, then means over 80 classes. The COCO headline number written "mAP" or "AP" is this $\text{AP}@[0.50{:}0.95]$, and it punishes loose localization far more than VOC's single lenient threshold does.

The size-stratified numbers (APs for small, APm for medium, APl for large objects) deserve a moment, because they reveal the single most consistent weakness of detectors: small objects score far lower than large ones, since a few-pixel box is hard to localize within $0.05$ IoU steps. When a vendor advertises a high overall mAP, asking for the APs is the fastest way to learn whether the model will work on the distant pedestrians or tiny defects you actually care about. Table 23.1.1 is the legend you should keep beside any detection benchmark.

# Score detections with the reference COCO evaluator instead of a hand-rolled AP.
# Load ground-truth and predictions in COCO JSON, then run the standard
# evaluate / accumulate / summarize sequence to print the full AP suite.
from pycocotools.coco import COCO
from pycocotools.cocoeval import COCOeval

coco_gt = COCO("instances_val.json")          # ground-truth annotations
coco_dt = coco_gt.loadRes("predictions.json") # your detections, COCO JSON format
ev = COCOeval(coco_gt, coco_dt, iouType="bbox")
ev.evaluate(); ev.accumulate(); ev.summarize()  # prints AP, AP50, AP75, APs/m/l

6. Putting It Together: A Tiny End-to-End Evaluation Intermediate

To make the matching rule concrete, the snippet below evaluates a handful of predictions against ground truth for one class on one image, labeling each prediction TP or FP, then feeds the result to our average_precision function. This is the inner loop that the COCO evaluator runs millions of times, written plainly.

def match_predictions(preds, gts, iou_thresh=0.5):
    """preds: list of (confidence, box). gts: list of box. Returns (conf, is_tp) list."""
    preds = sorted(preds, key=lambda p: -p[0])   # highest confidence first
    claimed = [False] * len(gts)
    results = []
    for conf, pbox in preds:
        best_iou, best_j = 0.0, -1
        for j, gbox in enumerate(gts):
            ov = iou(pbox, gbox)
            if ov > best_iou:
                best_iou, best_j = ov, j
        if best_iou >= iou_thresh and not claimed[best_j]:
            claimed[best_j] = True          # this GT is now taken
            results.append((conf, 1))       # true positive
        else:
            results.append((conf, 0))       # false positive (low IoU or duplicate)
    return results

gts = [[60, 60, 260, 210], [300, 300, 420, 420]]
preds = [(0.92, [62, 64, 258, 205]),   # good overlap with GT 0 -> TP
         (0.85, [70, 70, 250, 200]),   # duplicate of GT 0 -> FP (already claimed)
         (0.60, [305, 305, 418, 418])] # good overlap with GT 1 -> TP
matched = match_predictions(preds, gts)
print(matched)                                   # [(0.92, 1), (0.85, 0), (0.60, 1)]
print(round(average_precision(matched, len(gts)), 3))  # 1.0

That duplicate false positive is a preview of the chapter's central engineering problem. Dense detectors emit many overlapping boxes per object, and the evaluation rule above punishes every extra one. The two-stage and one-stage families in the next sections solve it with a post-processing step called non-maximum suppression; DETR in Section 23.5 solves it by predicting a clean set in the first place. Either way, the metric you just built is the judge that forces the issue.

The Metric Ladder: IoU, AP, mAP

The three metrics of this section form one ladder, each rung averaging the rung below. IoU judges one box against one truth (overlap over union). AP judges one class across every confidence threshold (the area under its precision-recall curve). mAP judges the whole detector across every class (the mean of the per-class APs), and the COCO protocol averages once more over ten IoU thresholds. The signature phrase to remember is IoU grades a box, mAP grades the detector; everything in between is bookkeeping that turns one box's overlap into the single decimal a leaderboard prints. When a later section cites "37.4 mAP", read it as "averaged over classes, over thresholds, over the whole dataset", never as one tight box. The illustration below pictures the ladder as a single nervous report-card grade built from its rungs.
