Bag of Visual Words & Spatial Pyramids

"Describe this picture? Easy. Three hundred corners, two hundred blobs, a smattering of edges, and not the faintest idea where any of them are. You are welcome."

A Bag of Visual Words With No Sense of Place

The previous section ended with a verdict: pixels are the wrong currency for recognition because they are invariant to nothing. Section 16.1 pointed at engineered features as the fix. This section takes the first and most influential step, turning the local descriptors you already know how to compute into a single fixed-length vector that describes a whole image, robustly enough to feed a category classifier. The whole construction is borrowed, almost line for line, from how search engines index text.

1. From Documents to Images: The Analogy Beginner

In text retrieval, the bag-of-words model represents a document by which words it contains and how often, ignoring word order entirely. "The cat sat on the mat" and "the mat sat on the cat" have identical bag-of-words representations. That sounds like a catastrophic loss of information, yet it is enough to cluster news articles, rank search results, and detect topics, because the set of words present is a strong signal of content even without order. Vision borrows the trick directly. The obstacle is that images do not come pre-segmented into words; we have to invent the vocabulary ourselves. The pipeline has four stages, and the rest of the section is one stage per subsection: detect and describe local features, build a vocabulary by clustering, encode each image as a word histogram, and classify.

2. Building the Visual Vocabulary Intermediate

A visual word is a representative descriptor, a cluster center in the space of local descriptors. To build the vocabulary we collect a large pool of descriptors from many training images and run k-means clustering with $K$ centers, where $K$ is the vocabulary size, typically a few hundred to a few thousand. Each of the $K$ resulting centroids is a visual word: a prototypical local appearance (a particular corner, a particular blob, a particular edge junction) that recurs across the corpus. The choice of $K$ trades expressiveness against generalization. Too small and distinct patterns collapse into one word; too large and the same physical pattern fragments across several words, so two images of the same object stop sharing words. Figure 16.2.1 places this clustering as the one offline stage of the pipeline.

The code below extracts SIFT descriptors from a set of training images and clusters them into a vocabulary. SIFT comes straight from Chapter 10; bag-of-words simply consumes its output.

# Build the visual vocabulary: pool SIFT descriptors from every training
# image, then run k-means so each of the K cluster centers becomes one
# visual word. This offline step is stage 2 of the pipeline.
import cv2
import numpy as np

sift = cv2.SIFT_create()

# Stage 1: pool descriptors from the whole training set.
all_descriptors = []
for path in training_image_paths:
    gray = cv2.imread(path, cv2.IMREAD_GRAYSCALE)
    _, desc = sift.detectAndCompute(gray, None)   # desc: (n_keypoints, 128)
    if desc is not None:
        all_descriptors.append(desc)
pool = np.vstack(all_descriptors).astype(np.float32)
print(f"pooled {pool.shape[0]} descriptors of dim {pool.shape[1]}")

# Stage 2: k-means builds the vocabulary; each center is one visual word.
K = 400
criteria = (cv2.TERM_CRITERIA_EPS + cv2.TERM_CRITERIA_MAX_ITER, 20, 1.0)
_, labels, vocabulary = cv2.kmeans(
    pool, K, None, criteria, attempts=3, flags=cv2.KMEANS_PP_CENTERS)
print(f"vocabulary shape: {vocabulary.shape}")    # (400, 128): 400 words
# pooled 318442 descriptors of dim 128
# vocabulary shape: (400, 128)

3. Encoding an Image as a Word Histogram Intermediate

With a vocabulary in hand, encoding any image is mechanical. Detect and describe its local features, assign each descriptor to its nearest visual word (the closest centroid), and count how many descriptors landed in each word. The result is a $K$-dimensional histogram: the bag of visual words. Two images of the same category produce similar histograms because they fire similar words at similar rates, regardless of where in the frame the features sat. That positional indifference is the encoding's central property, and we will spend the next subsection both praising and repairing it.

# Encode one image as a bag of visual words: assign each SIFT descriptor to
# its nearest vocabulary word, count the words into a K-dim histogram, and
# L1-normalize so images with different feature counts stay comparable.
import numpy as np
from scipy.cluster.vq import vq

def encode_bow(gray, sift, vocabulary):
    """Return an L1-normalized K-dim visual-word histogram for one image."""
    _, desc = sift.detectAndCompute(gray, None)
    K = vocabulary.shape[0]
    if desc is None:
        return np.zeros(K, dtype=np.float32)
    words, _ = vq(desc.astype(np.float32), vocabulary)  # nearest word per descriptor
    hist, _ = np.histogram(words, bins=np.arange(K + 1))
    hist = hist.astype(np.float32)
    return hist / (hist.sum() + 1e-9)                   # normalize away feature count

bow = encode_bow(cv2.imread("query.png", cv2.IMREAD_GRAYSCALE), sift, vocabulary)
print(f"histogram dim {bow.shape[0]}, sums to {bow.sum():.3f}, nonzero words {np.count_nonzero(bow)}")
# histogram dim 400, sums to 1.000, nonzero words 173

The normalization matters. A cluttered image fires more features than a sparse one, so raw counts would conflate "lots of texture" with "strong match." Dividing by the total turns counts into a distribution, the visual analog of term frequency in text. The text analogy goes one step further: just as the word "the" carries little discriminative power because it appears everywhere, a visual word that appears in nearly every image is uninformative. TF-IDF weighting downweights ubiquitous words and upweights rare, distinctive ones, exactly as in document retrieval, and it was the weighting that made the Video Google system (Sivic and Zisserman, ICCV 2003) work. The weight for word $w$ in image $d$ is

$$ \text{tfidf}(w, d) \;=\; \underbrace{\frac{n_{w,d}}{\sum_{w'} n_{w',d}}}_{\text{term frequency}} \;\cdot\; \underbrace{\log\frac{N}{n_w}}_{\text{inverse document frequency}}, $$

where $n_{w,d}$ counts word $w$ in image $d$, $N$ is the number of images, and $n_w$ is the number of images containing $w$ at all. The same machinery enables an inverted file: a lookup from each word to the list of images that contain it, which makes retrieval over millions of images fast and underpins the loop-closure step in the visual-SLAM systems of Chapter 14.

4. The Blind Spot, and the Spatial Pyramid Fix Intermediate

The bag-of-words encoding discards all geometry. This is genuinely useful: an object recognized by its parts survives translation, mild clutter, and occlusion, because the histogram does not care where the parts are or whether a few are missing. But the same blindness is a hard ceiling. A correct face and a scrambled face, eyes where the mouth should be, have identical word histograms, because both contain the same parts in the same counts. The encoding literally cannot represent layout, so it cannot distinguish arrangements, and scene categories that differ mainly by spatial structure (a coast is sky-above-water; a forest is texture-everywhere) confuse it.

The spatial pyramid (Lazebnik, Schmid and Ponce, CVPR 2006) buys back coarse geometry without abandoning the bag-of-words robustness. Partition the image into a sequence of ever-finer grids, a single $1 \times 1$ cell at level $0$, a $2 \times 2$ grid at level $1$, a $4 \times 4$ grid at level $2$, and so on, compute a separate word histogram inside each cell, and concatenate them all into one long vector. Now the representation knows roughly where each word fired (which cell), at multiple resolutions, while still being a histogram and still tolerating small misalignments within a cell. Figure 16.2.2 shows the three-level partition and how the per-cell histograms stack up.

The weighting in Figure 16.2.2 encodes the matching intuition: agreement at a fine resolution means the words really do sit in the same place, so it counts more, while the coarse level remains a safety net for objects that shifted between cells. With a three-level pyramid and a $400$-word vocabulary the concatenated vector has $(1 + 4 + 16) \times 400 = 8400$ dimensions, large but still a fixed length a linear classifier can handle. The code below builds it.

# Build a spatial-pyramid encoding: split the image into ever-finer grids,
# histogram the visual words inside each cell, weight finer levels more
# heavily, and concatenate every cell into one fixed-length vector.
import numpy as np
from scipy.cluster.vq import vq

def spatial_pyramid(gray, sift, vocabulary, levels=2):
    """Concatenate weighted word histograms over a 0..levels spatial pyramid."""
    kps, desc = sift.detectAndCompute(gray, None)
    K = vocabulary.shape[0]
    H, W = gray.shape
    if desc is None:
        n_cells = sum((2 ** l) ** 2 for l in range(levels + 1))
        return np.zeros(n_cells * K, dtype=np.float32)
    words, _ = vq(desc.astype(np.float32), vocabulary)
    xs = np.array([kp.pt[0] for kp in kps])
    ys = np.array([kp.pt[1] for kp in kps])

    blocks = []
    for level in range(levels + 1):
        n = 2 ** level                                  # n x n grid this level
        weight = 1.0 / 2 ** (levels - level)            # finer level -> larger weight
        for gy in range(n):
            for gx in range(n):
                in_cell = ((xs >= gx * W / n) & (xs < (gx + 1) * W / n) &
                           (ys >= gy * H / n) & (ys < (gy + 1) * H / n))
                hist, _ = np.histogram(words[in_cell], bins=np.arange(K + 1))
                blocks.append(weight * hist.astype(np.float32))
    vec = np.concatenate(blocks)
    return vec / (vec.sum() + 1e-9)

spm = spatial_pyramid(cv2.imread("scene.png", cv2.IMREAD_GRAYSCALE), sift, vocabulary)
print(f"spatial pyramid vector length: {spm.shape[0]}")   # 21 * K
# spatial pyramid vector length: 8400

5. Classifying the Histograms Beginner

Once every image is a fixed-length vector, recognition is ordinary supervised classification. A linear support vector machine (the subject of Section 16.3) works well, but bag-of-words histograms classify even better under a kernel matched to their nature. Because two histograms are compared most meaningfully by how their distributions overlap, the histogram intersection and chi-squared kernels outperform a plain linear one, and they were standard in the spatial-pyramid era. Each is just a similarity score between two histograms $\mathbf{a}$ and $\mathbf{b}$. Histogram intersection sums the per-bin minimum, $\sum_i \min(a_i, b_i)$, literally the shared area under the two histograms, so it rewards counts the two images hold in common and ignores the rest. The chi-squared kernel uses

$$ K(\mathbf{a}, \mathbf{b}) \;=\; \exp\!\left( -\gamma \sum_i \frac{(a_i - b_i)^2}{a_i + b_i} \right), $$

where the per-bin term $\tfrac{(a_i - b_i)^2}{a_i + b_i}$ divides each squared difference by the bin's own magnitude. That denominator is the whole point: a discrepancy of $0.1$ in a rare word (small $a_i + b_i$) counts far more than the same $0.1$ in a ubiquitous one. Put numbers on it: a rare word with $a_i = 0.10$ and $b_i = 0.00$ contributes $\tfrac{0.10^2}{0.10} = 0.10$, while a common word that differs by the same $0.1$ but sits high, $a_i = 0.50$ and $b_i = 0.40$, contributes only $\tfrac{0.10^2}{0.90} \approx 0.011$, roughly nine times less. So the kernel weights distinctive words heavily and shrugs off the noisy common ones, exactly the emphasis a plain Euclidean (linear) comparison cannot make. The code below trains a chi-squared-kernel SVM on the encoded training set, the classifier that closes the pipeline of Figure 16.2.1.

# Train the final category classifier on spatial-pyramid vectors using a
# chi-squared kernel SVM, the standard choice for visual-word histograms,
# then report accuracy on the encoded test set.
import numpy as np
from sklearn.svm import SVC
from sklearn.metrics.pairwise import chi2_kernel

# X_train: (n_images, 21*K) spatial-pyramid vectors; y_train: integer labels.
clf = SVC(kernel=chi2_kernel, C=10.0)   # chi-squared kernel suits histograms
clf.fit(X_train, y_train)

X_test_vec = np.array([spatial_pyramid(g, sift, vocabulary) for g in test_grays])
pred = clf.predict(X_test_vec)
acc = (pred == y_test).mean()
print(f"spatial-pyramid + chi2-SVM accuracy: {acc:.3f}")
# spatial-pyramid + chi2-SVM accuracy: 0.812

6. Beyond Counting: VLAD and Fisher Vectors Advanced

Counting which word each descriptor is nearest to throws away a lot: it records that a descriptor landed in cluster $c$ but forgets where inside the cluster it landed. The encodings that pushed bag-of-words to its peak accuracy keep that residual information. VLAD (Vector of Locally Aggregated Descriptors) stores, for each visual word, the sum of the differences between the assigned descriptors and the word's center: not just "how many" but "in which direction they deviated." For a $K$-word vocabulary of $D$-dimensional descriptors, VLAD produces a $K \times D$ vector,

$$ \mathbf{v}_c \;=\; \sum_{i : \text{NN}(x_i) = c} \big( x_i - \mu_c \big), \qquad \text{VLAD} = \big[\mathbf{v}_1, \mathbf{v}_2, \ldots, \mathbf{v}_K\big], $$

where $\mu_c$ is the $c$-th center. Fisher vectors go further still, modeling the descriptor distribution as a Gaussian mixture (the same weighted blend of a few Gaussian blobs used to model colors in the GrabCut segmentation of Section 11.4, here modeling descriptors instead) and recording the gradient of the data's log-likelihood with respect to the mixture parameters, capturing first and second order deviations (means and variances) per component. Both encodings let a much smaller vocabulary reach higher accuracy than a giant bag-of-words histogram, because each word now carries rich residual statistics instead of a single count. Fisher vectors held the top of image classification benchmarks right up until convolutional networks overtook them in 2012, a hand-off Section 16.6 examines closely.

# OpenCV's built-in bag-of-words encoder: BOWKMeansTrainer clusters the
# vocabulary and BOWImgDescriptorExtractor produces a per-image histogram,
# handling nearest-word assignment and normalization internally.
import cv2
bow_trainer = cv2.BOWKMeansTrainer(clusterCount=400)
for desc in training_descriptors:
    bow_trainer.add(desc)
vocabulary = bow_trainer.cluster()                 # k-means inside

extractor = cv2.BOWImgDescriptorExtractor(cv2.SIFT_create(), cv2.BFMatcher())
extractor.setVocabulary(vocabulary)
hist = extractor.compute(gray, cv2.SIFT_create().detect(gray))  # one normalized histogram
