Self-Distillation & Masked Image Modeling: DINO & MAE

"My teacher and I are the same network, separated only by time. She is a slow, smoothed average of everything I used to be, and my one job is to agree with her. Somehow, in the act of agreeing with my own past, I learned where the objects are."

A Student Network Distilling From Its Own Echo

The contrastive methods of Section 25.2 needed many negatives, and the research frontier there hinted that negatives might be unnecessary. This section makes good on that hint twice. First we build self-distillation, where a network learns by matching a smoothed copy of itself, and see why DINO's attention maps light up on objects. Then we build masked image modeling, where the supervision is reconstructing hidden content, and see why MAE's asymmetric design made it both effective and efficient. Both use the Vision Transformer of Chapter 22 as their backbone, and both exploit its patch structure. By the end you will understand the two pretraining objectives that, combined, produce DINOv2, the general-purpose backbone of Section 25.6.

1. Self-Distillation Without Labels Intermediate

Self-distillation borrows the teacher-student framing from knowledge distillation but removes the external teacher. Knowledge distillation, in its usual form, trains a small "student" network to imitate the output distribution of a larger, already-trained "teacher" network, transferring what the teacher learned into a cheaper model (it is a model-compression technique we return to in Section 28.1). Self-distillation keeps the imitation idea but drops the separate pretrained teacher: the teacher is a copy of the student whose weights are an exponential moving average of the student's. This is the momentum encoder from Section 25.2, promoted from a source of consistent negatives to the entire mechanism. The student sees one augmented view of an image and the teacher sees another; the student is trained to make its output distribution match the teacher's. There are no negatives and no labels: the only signal is "your two views of this image should produce the same soft prediction". The illustration below pictures this teacher as the student's own slower echo.

This immediately raises the collapse problem. If both networks simply output the same constant vector for every image, the matching loss is zero and nothing has been learned. DINO (Caron et al., 2021) prevents collapse with two operations applied to the teacher's output. Centering subtracts a running mean from the teacher's logits, which stops any single dimension from dominating. Sharpening uses a low temperature in the teacher's softmax, which makes its output confident and peaked. Centering alone would push toward a uniform distribution (collapse to uniform); sharpening alone would push toward a one-hot spike (collapse to a constant class). Applied together they balance, and the only stable solution is one where the network genuinely distinguishes images.

The sharpening also creates the learning pressure. Because the teacher's temperature is lower than the student's, the teacher's target is more confident than the student's current guess, so "match the teacher" always asks the student to commit a little further than it has. That pressure drives improvement, rather than letting both sides settle into agreement on a vague output. Figure 25.3.1 shows the asymmetric flow.

The code below implements the DINO loss, including the centering buffer update. The stop-gradient on the teacher is enforced by detach; the teacher weights are updated separately by the same momentum_update from Section 25.2.

import torch
import torch.nn.functional as F

class DINOLoss:
    def __init__(self, out_dim, teacher_temp=0.04, student_temp=0.1, center_m=0.9):
        self.center = torch.zeros(1, out_dim)   # running center subtracted from teacher
        self.tt, self.st, self.cm = teacher_temp, student_temp, center_m

    def __call__(self, student_out, teacher_out):
        # Student: ordinary softmax at higher temperature.
        student = F.log_softmax(student_out / self.st, dim=-1)
        # Teacher: center (anti-collapse) then sharpen (low temp), and stop gradient.
        teacher = F.softmax((teacher_out - self.center) / self.tt, dim=-1).detach()
        loss = -(teacher * student).sum(dim=-1).mean()        # cross-entropy to teacher
        # Update the center as an EMA of this batch's teacher outputs.
        self.center = self.cm * self.center + (1 - self.cm) * teacher_out.mean(0, keepdim=True)
        return loss

torch.manual_seed(0)
loss_fn = DINOLoss(out_dim=2048)
s, t = torch.randn(16, 2048), torch.randn(16, 2048)   # student & teacher projections
print("DINO loss:", round(loss_fn(s, t).item(), 4))
# DINO loss: 7.6...   (high for random outputs; drops as student learns to match teacher)

DINO's most celebrated result is emergent: the self-attention of the trained ViT's class token, with no segmentation labels anywhere in training, attends almost exactly to the foreground object. You can threshold those attention maps to get a usable object segmentation for free. This is the strongest evidence in the chapter that a good self-supervised objective does not just memorize textures; it discovers the structure of scenes. The descriptor the book has been learning to learn since Chapter 10 now localizes objects on its own.

2. Masked Image Modeling: Predict the Hidden Patches Intermediate

The second family takes a completely different route to free supervision, one borrowed directly from language models. In masked language modeling, a model is shown a sentence with some words hidden and trained to predict them; the supervision is the missing words, which require no labeling because they are simply removed from the input. Masked image modeling does the same with patches: hide a fraction of the image's patches and train the network to reconstruct them from the visible ones. The patch tokenization of Chapter 22 is what makes this natural; an image is already a sequence of patch tokens, so masking patches is exactly analogous to masking words.

The difficulty is that images are far more redundant than text. A masked word usually has few plausible completions, but a masked image patch can often be guessed by copying a neighbor, so masking a small fraction teaches little. MAE (He et al., 2022) made two decisions that turned this from a weak signal into a strong one. The first decision is about how much to hide: mask aggressively, removing seventy-five percent of patches, so reconstruction genuinely requires understanding the whole scene rather than local interpolation from a visible neighbor.

The second decision is about who processes what. MAE uses an asymmetric encoder-decoder. A large ViT encoder sees only the twenty-five percent of patches that remain visible; because that is a quarter of the usual sequence, the encoder stays cheap to run even though it is big. A small, shallow decoder then reconstructs the full image, taking the encoded visible patches together with learnable mask tokens placed at the hidden positions. Figure 25.3.2 lays out the pipeline.

The reconstruction loss is mean squared error between the predicted and true pixel values of the masked patches only,

where $\mathcal{M}$ is the set of masked patch indices, $x_p$ is the true patch, and $\hat{x}_p$ is the decoder's prediction. Computing the loss only on masked patches (not the visible ones) is deliberate: predicting patches you were shown is trivial and dilutes the signal. The masking and loss are short to express.

import torch

def random_masking(x, mask_ratio=0.75):
    """x: (B, N, D) patch tokens. Keep a random (1-mask_ratio) subset; return kept + mask."""
    B, N, D = x.shape
    keep = int(N * (1 - mask_ratio))
    noise = torch.rand(B, N, device=x.device)            # random score per patch
    order = noise.argsort(dim=1)                          # shuffle patch indices
    keep_idx = order[:, :keep]                            # indices of visible patches
    x_visible = torch.gather(x, 1, keep_idx.unsqueeze(-1).expand(-1, -1, D))
    mask = torch.ones(B, N, device=x.device)
    mask.scatter_(1, keep_idx, 0)                         # 1 where masked, 0 where visible
    return x_visible, mask, order

def mae_loss(pred, target, mask):
    """MSE on masked patches only. pred, target: (B, N, patch_dim); mask: (B, N)."""
    per_patch = ((pred - target) ** 2).mean(dim=-1)       # (B, N) MSE per patch
    return (per_patch * mask).sum() / mask.sum()          # average over MASKED patches only

x = torch.randn(2, 196, 768)                              # 2 images, 14x14 patches, dim 768
x_vis, mask, _ = random_masking(x)
print("visible patches:", x_vis.shape[1], "of", x.shape[1], "| masked:", int(mask[0].sum()))
# visible patches: 49 of 196 | masked: 147

The asymmetry is the efficiency win: because the heavy encoder sees only forty-nine of the one hundred ninety-six patches, MAE pretraining is several times faster than processing the full image, while the representations it learns are strong under fine-tuning. The decoder can be small for a complementary reason: it is discarded after pretraining, since only the encoder is kept as the downstream feature extractor. It exists solely to turn the encoder's output into a pixel prediction so the reconstruction loss has something to grade, not to learn a good representation itself, so spending capacity on it would be wasted; a shallow decoder is enough to define the training signal while keeping that signal pointed at the encoder. The contrast with DINO is worth holding onto: DINO produces features that are excellent under a linear probe and even segment objects, while MAE produces features that shine after fine-tuning. The two objectives push representations in complementary directions, which is exactly why DINOv2 in Section 25.6 combines them.

import torch, timm
# DINOv2 ViT-S/14, self-distilled + masked, features ready for a frozen probe:
dino = torch.hub.load("facebookresearch/dinov2", "dinov2_vits14")
# An MAE-pretrained ViT-B/16, set up for fine-tuning (classifier head attached):
mae = timm.create_model("vit_base_patch16_224.mae", pretrained=True, num_classes=1000)

3. Choosing Between the Two Advanced

DINO and MAE are not interchangeable, and knowing which to reach for matters in practice. The contrast is worth memorizing as a one-line rule: DINO for frozen, MAE for fine-tune. DINO-style self-distillation produces features that are immediately useful without any task training: high linear-probe accuracy, strong k-nearest-neighbor retrieval, and emergent segmentation, because the objective explicitly organizes the embedding space by image identity. MAE-style masked modeling produces features that are a superb initialization for fine-tuning but weaker under a frozen linear probe, because reconstruction does not directly cluster images by semantics. So if you will freeze the backbone and use its features directly (retrieval, clustering, few-shot, dense correspondence), prefer a DINO-family model; if you will fine-tune end to end on a labeled downstream task, MAE is an excellent starting point. The practical example below is a real version of this decision.

4. The Objectives, Formally Advanced

The intuition above is enough to use both methods, but the precise objectives reward a careful read: every design choice in DINO and MAE is visible in a single line of math, and the anti-collapse equilibrium in particular only becomes unambiguous once it is written down. This subsection states both objectives in full, then ties them to the broader family of self-supervised recipes.

The DINO objective

DINO (Caron et al., 2021) couples a student network $g_{\theta_s}$ and a teacher network $g_{\theta_t}$ that share the same architecture but not the same weights. Each maps an input view to a $K$-dimensional vector, which a temperature-scaled softmax turns into a distribution over $K$ "prototype" coordinates. The training signal is the cross-entropy of the teacher distribution into the student distribution, summed over matched views $x$ (teacher) and $x'$ (student) of the same image,

Here $P_t$ is the teacher's target distribution and $P_s$ the student's prediction; minimizing this cross-entropy pulls the student's distribution onto the teacher's. The student distribution is an ordinary softmax at student temperature $\tau_s$,

where $g_{\theta_s}(x)^{(i)}$ is the $i$-th of the $K$ output coordinates and $\tau_s$ controls how peaked the student's distribution is. The teacher distribution is the same softmax with two extra operations baked in: a subtracted center $c$ and a smaller temperature $\tau_t$,

The center $c$ is a running mean of the teacher's raw outputs over the batch (batch size $B$), updated as an exponential moving average with rate $m$, and subtracted from every teacher logit before the softmax. The teacher temperature $\tau_t < \tau_s$ is what sharpens: a smaller temperature divides the logits by a smaller number, exaggerating their differences and driving the teacher's distribution toward a single peak.

These two operations are the entire anti-collapse mechanism, and they act in direct opposition. Sharpening (small $\tau_t$) pushes the teacher toward a one-hot distribution; if it acted alone the network would collapse onto a single output coordinate for every image, the peaked-output collapse. Centering subtracts whatever coordinate the teacher currently favors on average, which pushes the distribution back toward uniform; if it acted alone the network would collapse to the constant uniform distribution, learning nothing. Because one force pulls toward a peak and the other toward uniform, they cancel at an interior equilibrium where the only way to keep the loss low is for the teacher to assign genuinely different distributions to genuinely different images. The teacher itself is never trained by gradients; its weights track the student as an exponential moving average,

with momentum $\lambda$ close to one, so the teacher is the slow, smoothed echo of the student described in this section's epigraph. No negative pairs appear anywhere: unlike the contrastive objectives of Section 25.2, DINO never contrasts an image against others in the batch, which is why the centering-plus-sharpening equilibrium has to do the anti-collapse work that negatives did before.

The MAE objective

MAE (He et al., 2022) replaces the matching game with reconstruction, and its design is built around one efficiency observation. After patchifying the image into tokens, MAE masks a random subset at a high ratio (seventy-five percent), then makes the encoder and decoder deliberately asymmetric: the encoder, a full ViT, processes only the visible quarter of patches and never sees a mask token, while a lightweight decoder reconstructs the image from the encoded visible tokens together with shared, learnable mask tokens inserted at the hidden positions. The reconstruction loss is mean squared error in pixel space, computed on the masked patches only,

where $\mathcal{M}$ is the set of masked patch indices, $x_p$ the ground-truth patch and $\hat{x}_p$ the decoder's prediction; in practice the per-patch targets are normalized (each patch standardized by its own mean and variance), which sharpens the local contrast the loss rewards. The two ideas compound into the headline efficiency win: a high mask ratio shortens every sequence, and because the heavy encoder skips the masked patches entirely it runs on only a quarter of the tokens, giving roughly a threefold speedup over encoding the full image while still learning a strong representation.

The PyTorch fragment below isolates the DINO anti-collapse machinery from the formal objective: the centering-then-sharpening of the teacher, the stop-gradient, the cross-entropy, and the two exponential moving averages (the center $c$ and the teacher weights $\theta_t$). It is the precise counterpart of the equations above.

import torch
import torch.nn.functional as F

@torch.no_grad()
def update_teacher(student, teacher, lam=0.996):
    # Teacher weights track the student as an EMA: theta_t <- lam*theta_t + (1-lam)*theta_s.
    for ps, pt in zip(student.parameters(), teacher.parameters()):
        pt.mul_(lam).add_(ps.detach(), alpha=1 - lam)

def dino_step(s_logits, t_logits, center, tau_s=0.1, tau_t=0.04, m=0.9):
    # Student: ordinary softmax at the higher temperature tau_s.
    p_s = F.log_softmax(s_logits / tau_s, dim=-1)
    # Teacher: CENTER (anti-collapse toward uniform) then SHARPEN (low tau_t -> peaked),
    # with a stop-gradient so no gradient reaches the teacher.
    p_t = F.softmax((t_logits - center) / tau_t, dim=-1).detach()
    loss = -(p_t * p_s).sum(dim=-1).mean()            # cross-entropy of teacher into student
    # Update the center as an EMA of this batch's raw teacher logits (opposes sharpening).
    center = m * center + (1 - m) * t_logits.mean(dim=0, keepdim=True)
    return loss, center

Three families, and the predictive successor

DINO and MAE are two of the three families of self-supervised vision learning, alongside the contrastive methods of Section 25.2. Contrastive learning pulls together views of the same image and pushes apart views of different images, using negatives; self-distillation (DINO) matches a student to a smoothed teacher with no negatives, relying on centering and sharpening to avoid collapse; masked reconstruction (MAE) predicts hidden pixels and needs neither negatives nor a teacher. The predictive-embedding successor that unifies the strengths of these lines is JEPA (Chapter 36), the Joint-Embedding Predictive Architecture. Like DINO and BYOL, JEPA learns against a stop-gradient EMA target rather than against negatives; unlike MAE, it does not predict in pixel space but in latent space, predicting the encoded representation of a masked region instead of its raw pixels, which spares the model from hallucinating imperceptible texture. We develop JEPA in full in Section 36.7; for now it is enough to see it as masked modeling moved out of pixel space and onto a stable EMA target, the same target mechanism that makes DINO work.
