Export & Runtimes: ONNX, TensorRT & OpenVINO

"In the lab they called me a model. The compiler called me a graph, fused half my layers into each other, picked different kernels for a GPU I had never met, and handed back something three times faster that I no longer fully recognized. I have made my peace with being optimized."

A Trained Network, Recently Compiled

In Section 28.1 we shrank a model but left it as a PyTorch nn.Module. That object is convenient for research and slow for production: every operation dispatches through Python, kernels are chosen generically, and intermediate tensors are written to and read from memory between every layer. Production wants the opposite of all three. This section is about getting there. We first separate the model from its framework with ONNX, then hand the ONNX graph to a runtime that compiles it. By the end you will be able to take any model from this book, a classifier from Chapter 20, a detector from Chapter 23, or a Vision Transformer from Chapter 22, and turn it into an engine that runs several times faster than the eager version, on the specific chip you are deploying to.

1. The Problem: Framework Is Not Runtime Beginner

You train in a framework (PyTorch, in this book) because frameworks are built for iteration: dynamic graphs, automatic differentiation, easy debugging. None of that helps at inference, and some of it actively hurts. At inference there are no gradients, the graph is fixed, and the only thing that matters is pushing inputs through to outputs as fast as possible on the deployment hardware. The deployment hardware, meanwhile, is rarely the workstation you trained on; it might be a different GPU, a server CPU, an embedded module, or a phone, each with its own optimal way to execute the same mathematics.

The solution is a two-layer separation, shown in Figure 28.2.1. A portable interchange format captures the trained model as a hardware-agnostic computation graph: a list of operators (convolution, matmul, add, relu) and the tensors flowing between them. A hardware-specific runtime then consumes that graph and compiles it into an executable optimized for one target. The interchange format means you export once and deploy many places; the runtime means each place runs the model the way that place runs best. ONNX is the dominant interchange format, and each major hardware vendor ships a runtime that consumes it. The illustration below captures the same single-crate, many-destinations idea.

2. ONNX: The Portable Graph Beginner

ONNX (Open Neural Network Exchange) is a serialization format for a computation graph plus its trained weights. Its operator set is a versioned, standardized vocabulary, so a Conv node means the same thing whether PyTorch, TensorFlow, or scikit-learn produced it. PyTorch exports to ONNX by tracing: it runs a forward pass with an example input, records every operator the tensors flow through, and writes that recorded graph to a file. Because the export is a trace, the example input's shape matters, and any control flow that depends on the data (a Python if branching on a tensor value) is captured only for the path the trace happened to take. This is why exportable inference code avoids data-dependent branching, a discipline that pays off across every runtime. The export call is short.

import torch
from torchvision.models import resnet18, ResNet18_Weights

model = resnet18(weights=ResNet18_Weights.DEFAULT).eval()
example = torch.randn(1, 3, 224, 224)

# torch.onnx.export traces a forward pass and writes the graph + weights.
torch.onnx.export(
    model, example, "resnet18.onnx",
    input_names=["input"], output_names=["logits"],
    # Mark axis 0 dynamic so the engine accepts any batch size at runtime.
    dynamic_axes={"input": {0: "batch"}, "logits": {0: "batch"}},
    opset_version=17,                  # the operator-set version to target
)
print("wrote resnet18.onnx")

# Validate the graph and check numerical agreement with PyTorch.
import onnxruntime as ort, numpy as np
sess = ort.InferenceSession("resnet18.onnx", providers=["CPUExecutionProvider"])
ort_out = sess.run(None, {"input": example.numpy()})[0]
torch_out = model(example).detach().numpy()
print("max abs diff:", np.abs(ort_out - torch_out).max())   # max abs diff: ~1e-5

3. What a Compiler Actually Does Intermediate

Here is the part that surprises people the first time they measure it: the compiled engine computes the exact same numbers as your eager model, yet runs several times faster. Where does the speed come from if the arithmetic is identical? A runtime does not just execute the ONNX graph node by node; it compiles it, and three optimizations do most of the work. Understanding them tells you why a compiled engine is faster and, just as usefully, where to look when it is not.

Operator fusion merges adjacent operators into a single kernel. A convolution followed by a batch-norm followed by a ReLU is, in the eager graph, three operators that each read their input from memory and write their output back. Fused, they become one kernel that reads the input once, does all three computations in registers, and writes the result once. Because deep networks are usually memory-bandwidth bound (moving tensors costs more than the arithmetic on them), eliminating those intermediate memory trips is often the largest single win. The batch-norm of Chapter 21 can even be folded entirely into the preceding convolution's weights at compile time, since at inference it is just an affine rescaling, removing it from the graph completely. Figure 28.2.2 shows the fusion.

Kernel autotuning picks the fastest implementation of each operator for the specific hardware. There are many ways to compute a convolution (direct, im2col-plus-matmul, Winograd, FFT-based, and several tiled GPU variants), and which is fastest depends on the layer's shape and the chip's cache sizes and core layout. TensorRT, during its build step, actually benchmarks several candidate kernels for each layer on the real device and keeps the winner. This is why building a TensorRT engine takes minutes and why the engine is tied to the exact GPU it was built on; the autotuning baked in choices specific to that silicon.

Precision calibration is the runtime-side half of the quantization from Section 28.1. Given a calibration dataset, the runtime measures activation ranges and chooses per-tensor scales so it can run layers in int8 (or FP16, or FP8 on newer hardware) while keeping accuracy. The runtime decides per layer whether the speed gain of lower precision is worth the accuracy cost, sometimes keeping a few sensitive layers in higher precision, a mixed-precision plan you could not easily hand-tune.

4. TensorRT: The NVIDIA GPU Runtime Intermediate

TensorRT is NVIDIA's inference compiler and runtime. It takes an ONNX graph (or a framework model through a plugin) and builds an engine: a serialized, hardware-tuned plan that the TensorRT runtime executes. The build does all three optimizations above for the target GPU. Engines are not portable across GPU architectures, so you build on (or for) the deployment device. The easiest path from ONNX to an engine is the trtexec command-line tool, and the same engine then runs from Python or C++. The snippet below shows the build and a Python timing harness; the comments give representative numbers from a mid-range GPU so you can see the shape of the win.

# --- Build an int8 engine from ONNX (shell command, run once on the target GPU) ---
# trtexec --onnx=resnet18.onnx --saveEngine=resnet18.engine \
#         --int8 --shapes=input:8x3x224x224
# The build autotunes kernels for THIS GPU and calibrates int8 ranges.

# --- Load and time the engine from Python ---
import tensorrt as trt
import numpy as np

logger = trt.Logger(trt.Logger.WARNING)
with open("resnet18.engine", "rb") as f:
    engine = trt.Runtime(logger).deserialize_cuda_engine(f.read())
context = engine.create_execution_context()

# (Allocate device buffers, copy input, run context.execute_async_v3, copy output.)
# The mechanics are runtime-version specific; the point is the measured latency:
#
#   eager PyTorch fp32 (batch 8) : 9.8 ms / batch
#   TensorRT fp16    (batch 8)   : 2.7 ms / batch   -> 3.6x faster
#   TensorRT int8    (batch 8)   : 1.9 ms / batch   -> 5.2x faster
#
# Always re-measure on YOUR GPU; these ratios shift with architecture and shape.
print("engine loaded; benchmark on the target device")

The most common practical wrinkle with TensorRT is the optimization profile: because the engine is tuned for specific input shapes, dynamic dimensions (variable batch size or image resolution) must be declared with a minimum, optimum, and maximum at build time, and the engine is fastest at the optimum. Forgetting this is why a dynamically shaped engine sometimes runs slower than expected, it is being executed away from the shape it was tuned for. This same engine, built for a Jetson rather than a data-center GPU, is the deployment path of Section 28.3.

5. OpenVINO: The CPU and Accelerator Runtime Intermediate

Not everything runs on an NVIDIA GPU. A great deal of vision inference runs on CPUs (servers without GPUs, industrial PCs, retail edge boxes) and on Intel's integrated GPUs and neural accelerators. OpenVINO is Intel's counterpart to TensorRT for that hardware. Its model optimizer compiles an ONNX or framework graph into an intermediate representation, applies the same family of fusions and precision optimizations, and runs it through a unified inference API that targets CPU, integrated GPU, or NPU with a single device string. The conversion and inference are a few lines.

import openvino as ov
import numpy as np

core = ov.Core()
# Read ONNX directly; OpenVINO converts and optimizes it internally.
model = core.read_model("resnet18.onnx")

# Compile for the target device: "CPU", "GPU" (Intel iGPU), or "NPU".
compiled = core.compile_model(model, device_name="CPU")

# Run inference. OpenVINO has already fused ops and chosen CPU-optimal kernels.
infer = compiled.create_infer_request()
x = np.random.randn(1, 3, 224, 224).astype(np.float32)
result = infer.infer({0: x})
logits = list(result.values())[0]
print("output shape:", logits.shape)         # output shape: (1, 1000)

# For int8, run OpenVINO's post-training quantization (NNCF) first; the compiled
# CPU engine then uses the VNNI integer instructions for a further 2-3x speedup.

The strategic point is portability through ONNX. The exact same resnet18.onnx file fed TensorRT in subsection 4 and OpenVINO here; the export work was done once. Table 28.2.1 summarizes when to reach for each runtime, including the cross-platform fallback, ONNX Runtime, which itself dispatches to TensorRT or OpenVINO under the hood through its execution-provider system when those are available.

# One checkpoint, three runtime targets: each export call runs the trace,
# opset selection, and runtime-specific build behind a single format string.
from ultralytics import YOLO
model = YOLO("yolo11n.pt")

model.export(format="onnx")        # portable ONNX graph
model.export(format="engine")      # builds a TensorRT engine on this GPU
model.export(format="openvino")    # OpenVINO IR for Intel CPU/iGPU/NPU
# Then run inference on the exported artifact with the same predict API:
YOLO("yolo11n.engine").predict("street.jpg")   # uses the TensorRT runtime

6. Summary and the Road to the Edge

Deployment requires separating the model from its framework. ONNX captures a trained model as a portable computation graph by tracing a forward pass; always validate the export numerically against the original. A runtime then compiles that graph for specific hardware, applying operator fusion (eliminating memory traffic), kernel autotuning (picking the fastest implementation per layer per chip), and precision calibration (running int8 or FP8 where accuracy allows). TensorRT serves NVIDIA GPUs and builds device-locked engines tuned with optimization profiles; OpenVINO serves Intel CPUs and accelerators; ONNX Runtime is the portable fallback. With a compiled engine in hand, the next question is the hardware it runs on. Section 28.3 takes these same runtimes to the edge: the Jetson modules, the mobile runtimes, and the architectures designed for a power budget measured in single-digit watts.
