Sampling & Quantization

"I used to be a continuous function with infinite detail. Then I got sampled at 512 by 512 and rounded to 8 bits. You adapt."

A Recently Discretized Signal

In Section 1.1 we followed light through the lens and sensor to a RAW mosaic. We glossed over the most fundamental step of all: the optical image projected onto the sensor is a continuous function of position and brightness, and the array in your program is neither. Formally, the scene presents an irradiance function $f(x, y)$ defined at every real-valued point and taking real values. The sensor turns it into $f[m, n]$, defined only at integer grid positions (sampling), and the ADC turns each value into one of finitely many integers (quantization). Two axes of discretization, two failure modes, two sets of engineering tools, which is exactly how this section is organized.

1. Sampling: From Function to Grid Beginner

Sampling evaluates the continuous image on a regular lattice with horizontal pitch $\Delta x$ and vertical pitch $\Delta y$:

A persistent misconception, worth killing early, is that a pixel is a little square of color. A pixel is a sample: a single measurement associated with a point (in practice, a small area-average around that point, since photosites integrate light over their surface). The little-square picture causes real bugs, for example when aligning coordinate systems during the geometric warps of Chapter 5, where the question "is pixel (0,0) the corner or the center of the first sample area?" changes results by half a pixel.

How fine must the grid be? The celebrated sampling theorem of Nyquist and Shannon answers precisely: a signal can be perfectly reconstructed from its samples if it contains no frequency at or above half the sampling rate,

where for images "frequency" means cycles per unit distance: fine stripes are high frequency, smooth washes are low frequency. The full machinery behind this statement (Fourier transforms, spectra, and the elegant proof) arrives in Chapter 4; what you need now is the consequence of violating it.

2. Aliasing: When Detail Lies Intermediate

When the scene contains frequencies above the Nyquist limit, those frequencies do not disappear from the sampled image. They fold back, masquerading as lower frequencies that were never in the scene. This is aliasing, and you have seen it: the wagon-wheel that spins backwards on film, the shimmering moire on a striped shirt in a video call, the jagged staircase on a rendered diagonal line. The defining property of aliasing is that it manufactures plausible-looking false structure, which is what makes it dangerous for measurement and for machine learning alike.

The torture test for aliasing is the zone plate, a pattern whose frequency grows steadily with radius. Code 1.2.1 builds one and downsamples it two ways: naive pixel-dropping versus area averaging.

import cv2
import numpy as np

# Zone plate: spatial frequency increases with radius, a torture test
# for any resampling code.
n = 512
y, x = np.mgrid[0:n, 0:n].astype(np.float32)
r2 = (x - n / 2) ** 2 + (y - n / 2) ** 2
zone = (127.5 + 127.5 * np.cos(np.pi * r2 / 256.0)).astype(np.uint8)

# Downsample 4x by simply keeping every 4th pixel (no pre-filter):
small_naive = cv2.resize(zone, (n // 4, n // 4),
                         interpolation=cv2.INTER_NEAREST)
# Downsample 4x by averaging each 4x4 block (a built-in anti-alias filter):
small_clean = cv2.resize(zone, (n // 4, n // 4),
                         interpolation=cv2.INTER_AREA)

cv2.imwrite("zone_full.png", zone)
cv2.imwrite("zone_naive.png", small_naive)  # ghost rings: aliasing
cv2.imwrite("zone_clean.png", small_clean)  # fine rings fade to flat gray

Open the three saved files side by side and the lesson is immediate: the naive version contains concentric rings that simply do not exist in the original at those positions, while the area-averaged version degrades gracefully. The general rule, which you will use every time you build an image pyramid in Chapter 4 or resize a training set, is to remove the frequencies the new grid cannot carry before resampling, usually with a Gaussian or box blur.

import cv2
from skimage.transform import rescale

small = cv2.resize(img, None, fx=0.25, fy=0.25,
                   interpolation=cv2.INTER_AREA)        # box pre-filter
small2 = rescale(img, 0.25, anti_aliasing=True,
                 channel_axis=-1)                       # Gaussian pre-filter

3. Quantization: From Real Values to Integer Levels Intermediate

The second discretization acts on brightness. A $b$-bit quantizer maps the continuous range of measured intensities onto $L = 2^b$ discrete levels. With uniform spacing, the step size between adjacent levels is

and every true value within a step gets rounded to that step's representative. The rounding error is at most $\Delta/2$ per pixel, and if the true values are spread evenly within each step, the mean squared error of quantization is the classic result

which translates into a signal-to-noise ratio that improves by about $6.02$ dB for every added bit. Eight bits give roughly 48 to 50 dB, comfortably below what most humans can spot in a photograph viewed casually; that is why 8-bit images dominate, as we saw when handling dtypes in Chapter 0.

The visible failure of coarse quantization is banding (also called posterization or false contouring): smooth gradients break into discrete plateaus with visible seams. The eye is exquisitely sensitive to these seams because they look like edges, and edges carry meaning. Code 1.2.3 quantizes a smooth ramp to decreasing bit depths so you can find your own threshold of visibility.

import numpy as np
import cv2

# A perfectly smooth horizontal ramp, 0 to 255 across 1024 columns.
ramp = np.tile(np.linspace(0, 255, 1024, dtype=np.float32), (128, 1))

def quantize(img, bits):
    """Uniformly requantize a [0, 255] image to 2**bits levels."""
    levels = 2 ** bits
    step = 255.0 / (levels - 1)
    return (np.round(img / step) * step).astype(np.uint8)

panels = []
for bits in [8, 5, 3, 2]:
    q = quantize(ramp, bits)
    panels.append(q)
    print(f"{bits} bits -> {len(np.unique(q)):>3} distinct levels")

cv2.imwrite("banding.png", np.vstack(panels))  # stacked for comparison

8 bits -> 256 distinct levels
5 bits ->  32 distinct levels
3 bits ->   8 distinct levels
2 bits ->   4 distinct levels

Figure 1.2.1 puts the two discretizations side by side on a one-dimensional slice, because seeing them as separate operations is the key mental model: sampling acts on the horizontal axis, quantization on the vertical one.

4. Dithering: Trading Banding for Noise Advanced

Quantization error is deterministic: every pixel in a band rounds the same way, which is precisely why the eye sees a contour. Dithering breaks that determinism by adding controlled randomness, replacing correlated banding with uncorrelated grain that the eye averages away. The classic algorithm is Floyd-Steinberg error diffusion: quantize each pixel, then push its rounding error onto the not-yet-visited neighbors so that errors cancel locally. Code 1.2.4 implements it from scratch.

import numpy as np

def floyd_steinberg(gray, levels=2):
    """Quantize to `levels` while diffusing each pixel's rounding error
    onto its unvisited neighbors (right, lower-left, lower, lower-right)."""
    img = gray.astype(np.float32).copy()
    h, w = img.shape
    step = 255.0 / (levels - 1)
    for r in range(h):
        for c in range(w):
            old = img[r, c]
            new = np.clip(np.round(old / step) * step, 0, 255)
            img[r, c] = new
            err = old - new
            if c + 1 < w:
                img[r, c + 1] += err * 7 / 16
            if r + 1 < h:
                if c > 0:
                    img[r + 1, c - 1] += err * 3 / 16
                img[r + 1, c] += err * 5 / 16
                if c + 1 < w:
                    img[r + 1, c + 1] += err * 1 / 16
    return img.astype(np.uint8)

# Compare: hard 1-bit threshold vs dithered 1-bit, on the ramp from Code 1.2.3
ramp8 = np.tile(np.linspace(0, 255, 1024), (128, 1)).astype(np.uint8)
hard = np.where(ramp8 >= 128, 255, 0).astype(np.uint8)   # 2 flat halves
dith = floyd_steinberg(ramp8, levels=2)                  # smooth-looking ramp
print("hard levels:", np.unique(hard), " dithered levels:", np.unique(dith))

The deep idea, worth savoring, is that dithering does not reduce error energy at all; it reshapes the error spectrum, moving it from visible low-frequency contours into high-frequency noise the visual system discounts. The same principle reappears wearing different costumes throughout this book: noise shaping in audio, stochastic rounding when training neural networks in low precision, and the deliberate noise injection at the heart of the diffusion models of Chapter 33.

from PIL import Image

bw = Image.fromarray(ramp8).convert("1")  # 1-bit, Floyd-Steinberg by default
pal = Image.fromarray(ramp8).convert("P",
        palette=Image.Palette.ADAPTIVE, colors=8)  # dithered 8-color version

5. Budgeting Pixels and Bits Beginner

Sampling density and bit depth are budget decisions, and they interact with everything downstream. More samples cost memory, bandwidth, and compute quadratically; more bits cost linearly but stress storage formats and tooling. The right split depends on the consumer. Human viewing tolerates 8 bits but hates aliasing. Measurement tasks (gauging, medical, astronomy) often need 12 to 16 bits but modest resolution. Deep networks ingest surprisingly low resolutions (224×224 remains a standard training size) but are sensitive to aliasing introduced by careless dataset resizing, a pitfall that resurfaces in the augmentation pipelines of Chapter 21. The next section, Section 1.3, takes up this budgeting question quantitatively: what resolution, depth, and dynamic range actually buy you.
