Color Science & Color Spaces: RGB, HSV, Lab & YCbCr

"Hue is just an angle, saturation is just a radius, and yet everyone insists I have a personality."

A Mildly Desaturated Color Channel

Section 1.3 closed the books on the brightness of a single channel. This section explains the channel dimension itself: why three numbers, what they mean, and why the same pixel wears different coordinates in different spaces. The "why three" has a biological answer. Human retinas carry three cone types with broad, overlapping spectral sensitivities; every physical light spectrum, no matter how complex, is collapsed into three cone responses. Two physically different spectra that produce the same three responses (metamers) are literally the same color to us. Trichromacy is why cameras have three channels, displays have three primaries, and your arrays from Chapter 0 have shape (H, W, 3): machines copied our compression scheme.

1. From Spectra to Coordinates Beginner

Color science formalized trichromacy in 1931, when the CIE defined the XYZ color space from color-matching experiments: a device-independent reference in which any visible color has coordinates, and against which every practical color space is defined. You will rarely manipulate XYZ directly, but it is the hub through which conversions like RGB to Lab actually travel, and it pins down two ideas this section relies on. First, a white point: the XYZ coordinates declared to be "white" (daylight D65 for nearly all imaging), which anchors white balance from Section 1.1. Second, a gamut: the volume of colors a device can produce; sRGB, the default space of consumer imaging and the web, covers a modest gamut chosen to match 1990s CRT phosphors, and remains the assumed encoding of virtually every dataset you will train on.

2. RGB and the Gamma Trap Intermediate

The RGB values in an ordinary image file are not linear light measurements. As Figure 1.1.1 showed, the ISP applies a gamma curve: sRGB stores approximately the 1/2.2 power of linear intensity, spending more code values on dark tones, where human vision is most discriminating, which is quantization wisdom straight out of Section 1.2. The exact sRGB encoding is piecewise:

where $L$ is linear intensity in $[0, 1]$. The trap: arithmetic that is physically meaningful on linear light (averaging, blurring, resizing, alpha blending) is applied daily to gamma-encoded values, where it is quietly wrong. Code 1.4.1 shows the canonical symptom.

import numpy as np

def srgb_to_linear(v):
    v = v / 255.0
    return np.where(v <= 0.04045, v / 12.92, ((v + 0.055) / 1.055) ** 2.4)

def linear_to_srgb(L):
    s = np.where(L <= 0.0031308, 12.92 * L, 1.055 * L ** (1 / 2.4) - 0.055)
    return np.clip(255 * s, 0, 255)

red   = np.array([255.0, 0.0, 0.0])
green = np.array([0.0, 255.0, 0.0])

naive  = (red + green) / 2                      # averaging the CODES
proper = linear_to_srgb((srgb_to_linear(red) + srgb_to_linear(green)) / 2)

print("average of codes :", naive.round(0))     # dark, muddy olive
print("average of light :", proper.round(0))    # the yellow a camera would see

average of codes : [128. 128.   0.]
average of light : [188. 188.   0.]

3. HSV: Color the Way You Describe It Beginner

RGB answers "how much of each primary?", which is the wrong question for tasks like "select everything red-ish". HSV re-parameterizes the same cube into hue (which color, as an angle around a color wheel), saturation (how vivid, as a radius from gray), and value (how bright). Figure 1.4.1 shows the geometric relationship: HSV is the RGB cube stood on its black corner and described in cylindrical coordinates.

HSV's killer application is color-based selection: a "red object" occupies a narrow hue interval regardless of how bright or washed-out it appears, so a box in HSV often replaces an awkward curved region in RGB. This is the workhorse of classical color segmentation, which Chapter 11 develops fully, and of the threshold-based masks of Chapter 2. Two OpenCV quirks ambush everyone: hue is stored halved (range 0 to 179) so it fits in a uint8, and red sits at the wraparound, needing two ranges. Code 1.4.2 handles both.

import cv2
import numpy as np

# Self-contained scene: three colored disks on gray.
img = np.full((240, 320, 3), 128, np.uint8)
cv2.circle(img, (80, 120), 40, (0, 0, 220), -1)    # red disk (BGR order!)
cv2.circle(img, (160, 120), 40, (0, 200, 0), -1)   # green disk
cv2.circle(img, (240, 120), 40, (200, 80, 0), -1)  # blue disk

hsv = cv2.cvtColor(img, cv2.COLOR_BGR2HSV)

# Red hue straddles 0 degrees, so it needs TWO inRange windows.
# Reminder: OpenCV stores hue as degrees/2, so the wheel ends at 179.
mask = (cv2.inRange(hsv, (0, 80, 60), (10, 255, 255))
        | cv2.inRange(hsv, (170, 80, 60), (179, 255, 255)))

print("red pixels selected:", int(mask.sum() // 255))
print("true disk area     :", cv2.countNonZero(
      cv2.circle(np.zeros((240, 320), np.uint8), (80, 120), 40, 255, -1)))

4. Lab: When Distance Must Mean Difference Advanced

Neither RGB nor HSV distances track perception: two greens 20 units apart can look identical while two grays 20 units apart look clearly different. CIE Lab was engineered so that Euclidean distance approximates perceived difference. It separates lightness $L^*$ from two opponent axes, $a^*$ (green to red) and $b^*$ (blue to yellow), echoing the opponent-color wiring of human vision, and applies a cube-root nonlinearity matching perceptual compression:

with $L^* = 116 f(Y/Y_n) - 16$, $a^* = 500\,[f(X/X_n) - f(Y/Y_n)]$, and $b^* = 200\,[f(Y/Y_n) - f(Z/Z_n)]$, where $(X_n, Y_n, Z_n)$ is the white point. The payoff is $\Delta E$, the industry-standard color difference: $\Delta E_{76}$ is plain Euclidean distance in Lab, and the refined $\Delta E_{2000}$ corrects its known biases. A $\Delta E$ near 1 is a just-noticeable difference; below 2 is commercially "the same color" in most industries. Code 1.4.3 measures whether two production batches match.

import numpy as np
from skimage import color

# Two batches of "brand orange" that look identical in isolation.
batch_a = np.array([[[235, 122, 36]]], dtype=np.float64) / 255
batch_b = np.array([[[241, 117, 29]]], dtype=np.float64) / 255

lab_a = color.rgb2lab(batch_a)     # handles sRGB decoding + D65 white point
lab_b = color.rgb2lab(batch_b)

de76 = float(np.linalg.norm(lab_a - lab_b))
de2000 = float(color.deltaE_ciede2000(lab_a, lab_b)[0, 0])
print(f"Delta E 1976: {de76:.2f}   Delta E 2000: {de2000:.2f}")
# A Delta E 2000 under ~2.0 passes most print/brand color tolerances.

5. YCbCr: Color for Compression Intermediate

The final space exists for neither perception nor intuition but for bandwidth. Human vision resolves brightness detail far more sharply than color detail, so codecs split images into luma $Y'$ (a weighted sum of gamma-encoded R, G, B reflecting the eye's sensitivities) and two chroma differences:

with $C_b$ and $C_r$ encoding blue-difference and red-difference. The reward is chroma subsampling: storing chroma at half resolution in each direction (the 4:2:0 scheme) discards 50% of the data before any compression begins, almost invisibly. JPEG, WebP, and essentially every video codec do this, as Section 1.5 will exploit. Code 1.4.4 simulates the round trip and measures how little is lost on a typical image.

import cv2
import numpy as np

ycc = cv2.cvtColor(img, cv2.COLOR_BGR2YCrCb)   # OpenCV channel order: Y, Cr, Cb!
Y, Cr, Cb = cv2.split(ycc)

def to_quarter_and_back(c):
    """4:2:0 simulation: halve chroma resolution, then upsample back."""
    down = cv2.resize(c, None, fx=0.5, fy=0.5, interpolation=cv2.INTER_AREA)
    return cv2.resize(down, (c.shape[1], c.shape[0]),
                      interpolation=cv2.INTER_LINEAR)

ycc_sub = cv2.merge([Y, to_quarter_and_back(Cr), to_quarter_and_back(Cb)])
back = cv2.cvtColor(ycc_sub, cv2.COLOR_YCrCb2BGR)

err = np.abs(back.astype(np.int16) - img.astype(np.int16))
print("mean abs error after 4:2:0 round trip:", round(float(err.mean()), 2))
print("worst error (at colored disk edges) :", int(err.max()))

Four spaces, four jobs: RGB stores what devices emit, HSV indexes what humans mean, Lab measures what humans see, and YCbCr packs what channels can afford. With color encoded, one question remains for this chapter: how the whole array gets squeezed into a file, and what that squeezing costs. On to Section 1.5.
