Thresholding: Global, Otsu & Adaptive

"There are exactly two kinds of pixels in this world. I decided that. You're welcome."

An Uncompromisingly Binary Threshold Operator

The previous sections remapped intensities while keeping them continuous: Section 2.1 bent the tone curve and Section 2.3 let the histogram choose it. Now we collapse the scale entirely. Thresholding replaces every pixel with a yes or a no, which sounds destructive (and is) but is precisely the point: counting cells under a microscope, reading a barcode, locating solder joints, and OCRing a receipt all require deciding which pixels belong to the thing. This section covers choosing that decision boundary: by hand, optimally from the histogram, and locally when one global answer cannot exist.

1. Binarization: The Simplest Classifier Basic

Global thresholding is a one-parameter point operation:

$$g(x, y) = \begin{cases} 255 & \text{if } f(x, y) > T \\ 0 & \text{otherwise} \end{cases}$$

It is worth pausing on what this really is: a classifier with a single feature (intensity) and a single learned parameter ($T$). When does such a crude classifier work? Exactly when the histogram from Section 2.2 is bimodal: two well-separated humps, one for background and one for object, with a quiet valley between them. Then any $T$ in the valley yields a clean mask. Figure 2.4.1 shows this ideal case, along with the quantity Otsu's method will optimize. When the humps overlap (and the sensor noise we traced in Chapter 1 broadens both of them), no global $T$ can be clean, and we will need either better lighting, the local methods of this section's second half, or the learned segmentation of Part III.

In OpenCV, global thresholding is cv2.threshold, which returns both the threshold used and the binarized image, and supports inverse and truncation variants through its flag argument. The interesting question is not the call but the number: who chooses $T$?

2. Otsu's Method: The Histogram Chooses the Cut Advanced

Nobuyuki Otsu's 1979 insight reframed threshold selection as a clustering problem on the histogram. A candidate threshold $t$ splits the normalized histogram $p(k)$ into class 0 ($k \le t$) and class 1 ($k > t$), with class weights and means

$$\omega_0(t) = \sum_{k=0}^{t} p(k), \quad \omega_1(t) = 1 - \omega_0(t), \quad \mu_0(t) = \frac{\sum_{k=0}^{t} k\,p(k)}{\omega_0(t)}, \quad \mu_1(t) = \frac{\sum_{k=t+1}^{255} k\,p(k)}{\omega_1(t)}$$

A good threshold should produce two tight, well-separated classes: small variance within each class, large distance between their means. Otsu showed these are the same objective, because total variance decomposes as $\sigma^2 = \sigma_W^2(t) + \sigma_B^2(t)$: within-class plus between-class. Since $\sigma^2$ is fixed, minimizing the within-class spread equals maximizing the between-class variance

$$\sigma_B^2(t) = \omega_0(t)\, \omega_1(t)\, \big(\mu_0(t) - \mu_1(t)\big)^2$$

and the optimal threshold is $t^* = \arg\max_t \sigma_B^2(t)$. With only 256 candidates, brute force is instant, and cumulative sums make the whole search a few vectorized lines:

import numpy as np
import cv2

def otsu_threshold(gray):
    """Otsu's method from scratch: maximize between-class variance."""
    hist = np.bincount(gray.ravel(), minlength=256).astype(np.float64)
    p = hist / hist.sum()
    k = np.arange(256)

    w0 = np.cumsum(p)                      # class-0 weight for every t
    m  = np.cumsum(k * p)                  # cumulative first moment
    mG = m[-1]                             # global mean

    w1 = 1.0 - w0
    valid = (w0 > 0) & (w1 > 0)            # both classes must be non-empty
    mu0 = np.where(valid, m / np.maximum(w0, 1e-12), 0)
    mu1 = np.where(valid, (mG - m) / np.maximum(w1, 1e-12), 0)

    sigma_b2 = np.where(valid, w0 * w1 * (mu0 - mu1) ** 2, 0)
    return int(np.argmax(sigma_b2))

# Synthetic sanity check: dark background N(70, 12), bright blobs N(180, 12)
rng = np.random.default_rng(0)
img = rng.normal(70, 12, (400, 400))
img[100:300, 100:300] = rng.normal(180, 12, (200, 200))
img = np.clip(img, 0, 255).astype(np.uint8)

t_scratch = otsu_threshold(img)
t_cv, binary = cv2.threshold(img, 0, 255, cv2.THRESH_BINARY + cv2.THRESH_OTSU)
print(t_scratch, t_cv)   # 124 124.0  (the valley between 70 and 180)

t, binary = cv2.threshold(gray, 0, 255, cv2.THRESH_BINARY + cv2.THRESH_OTSU)

3. When One Threshold Cannot Work: Adaptive Methods Intermediate

Otsu optimizes a global cut, and some images simply do not have one. The canonical case is a document photographed under side lighting: the paper at the bright corner is lighter than the ink at the dark corner, so any single $T$ misclassifies one end of the page. Figure 2.4.2 shows the failure and the cure. The cure is to let the threshold vary across the image: classify each pixel against a statistic of its own neighborhood rather than against one global number.

OpenCV's cv2.adaptiveThreshold computes, for each pixel, the mean (or Gaussian-weighted mean) of a blockSize x blockSize neighborhood and thresholds the pixel at that local mean minus a constant C. For harder material (stained documents, low contrast film scans), Sauvola's method additionally scales the offset by the local standard deviation, so the threshold tightens in busy regions and relaxes in flat ones:

import cv2
from skimage.filters import threshold_sauvola

gray = cv2.imread("receipt_photo.jpg", cv2.IMREAD_GRAYSCALE)

# Local Gaussian-weighted mean, minus offset C. blockSize must be odd
# and larger than the stroke width of the text.
adaptive = cv2.adaptiveThreshold(gray, 255,
                                 cv2.ADAPTIVE_THRESH_GAUSSIAN_C,
                                 cv2.THRESH_BINARY,
                                 blockSize=31, C=10)

# Sauvola: threshold = mean * (1 + k * (std/R - 1)), per pixel
t_sauvola = threshold_sauvola(gray, window_size=31, k=0.2)
sauvola = (gray > t_sauvola).astype("uint8") * 255

Two parameter rules of thumb save hours of fiddling. First, blockSize (or window_size) must be larger than the features you are extracting: if the window fits inside a pen stroke, the stroke's interior sees only itself as context and dissolves. Second, C (or Sauvola's k) sets how decisively a pixel must differ from its surroundings to count as foreground; raising it suppresses noise speckle at the cost of thin strokes. Speckle that survives is not a thresholding failure but a job for the smoothing filters of Chapter 3, and for the morphological cleanup of Chapter 6, which consumes exactly the binary maps this section produces.

4. Beyond a Single Cut Intermediate

Three refinements round out the thresholding toolbox. Multi-level thresholding generalizes Otsu to two or more cuts (three classes or more); scikit-image ships it as threshold_multiotsu, useful for images with distinct material phases, like soil-pore-water micrographs. The triangle method (cv2.THRESH_TRIANGLE) handles strongly unimodal histograms with a small foreground tail, the regime where Otsu's equal-cluster assumption breaks, by dropping a perpendicular from the histogram peak's chord; it is a favorite in fluorescence microscopy. And hysteresis thresholding uses two thresholds: pixels above the high cut are definitely foreground, pixels between the cuts are accepted only if connected to definite ones. That last idea, tolerance for weak evidence when it is attached to strong evidence, is the heart of the Canny edge detector you will meet in Chapter 9.

Step back and notice the shape of everything this section did: produce a per-pixel score, then apply a cut to make a per-pixel decision. That shape survives the deep learning revolution completely intact. A semantic segmentation network in Chapter 24 ends in exactly this operation: per-pixel logits, a sigmoid, and a threshold (usually 0.5, and choosing it better is a tuning lever practitioners use). The score map got smarter; the final operation is still this section.
