Image Arithmetic, Blending & Compositing

"I am 30 percent mountain, 70 percent weather graphics, and 100 percent committed to this relationship."

A Partially Transparent Alpha Channel

Subtract last night's empty parking lot from this morning's and the cars light up instantly; this is the entire idea behind security motion detection, and it is two images, one minus sign, per pixel. Through Section 2.1 to Section 2.4 every operation touched a single image; now we let images combine. Given two aligned frames $f_1$ and $f_2$, we compute $f_1 + f_2$, $f_1 - f_2$, or $\alpha f_1 + (1-\alpha) f_2$ at every pixel, and that one step buys change detection, crossfades, watermarking, and compositing. The operations stay within the point-operation family (each output pixel depends only on the input pixels at the same location), but the inputs now come from multiple images, which is where the first trap lies waiting.

1. The Arithmetic Trap: uint8 Overflow Basic

As established in Chapter 0, images arrive as uint8 arrays, and uint8 arithmetic in NumPy is modular: it wraps around at 256 rather than stopping at 255. Adding two bright pixels yields a dark one; subtracting a larger value from a smaller one yields a bright one. OpenCV's arithmetic functions instead saturate, clamping results into $[0, 255]$. The two-line demonstration below is worth running once in your life, because the bug it represents is endemic. The illustration below shows the trap in action: two bright pixels add up and the counter rolls past its maximum back to black.

# The uint8 arithmetic trap: NumPy's +/- wrap around at 256 (modular),
# while OpenCV's cv2.add / cv2.subtract saturate into [0, 255]. Same
# inputs, opposite answers; cv2.absdiff sidesteps the sign issue.
import numpy as np
import cv2

a = np.array([[200]], dtype=np.uint8)
b = np.array([[100]], dtype=np.uint8)

print(a + b)            # [[44]]   NumPy wraps: (200 + 100) % 256 = 44
print(cv2.add(a, b))    # [[255]]  OpenCV saturates: min(300, 255)

print(b - a)                 # [[156]]  NumPy wraps: (100 - 200) % 256
print(cv2.subtract(b, a))    # [[0]]    OpenCV saturates: max(-100, 0)
print(cv2.absdiff(a, b))     # [[100]]  |200 - 100|, always safe

The symptoms of wraparound in real pipelines are unforgettable: brightened skies turn black in blotches, difference images light up like neon. The one-line rule to carry: never let uint8 do its own math. Either use the saturating cv2.add, cv2.subtract, cv2.absdiff, and cv2.addWeighted for uint8 work, or widen the type first (astype(np.float32) or np.int16), compute, then clip and convert back, exactly the float-clip-convert discipline from Section 2.1.

2. Blending: The Weighted Average Basic

The most useful two-image operation is the convex combination

$$g = \alpha f_1 + (1 - \alpha) f_2, \qquad \alpha \in [0, 1]$$

which crossfades between the images: $\alpha = 1$ shows pure $f_1$, $\alpha = 0$ pure $f_2$, and anything between is a dissolve. One call does it with saturation handled:

# Convex-combination blending with cv2.addWeighted (saturation handled):
# sweeping alpha from 1 to 0 dissolves one image into another, and the
# same call with a lopsided weight stamps a translucent watermark.
import cv2
import numpy as np

day   = cv2.imread("street_day.jpg")
night = cv2.imread("street_night.jpg")     # same size and dtype

# A 60-frame crossfade from day to night:
frames = []
for i in range(60):
    alpha = 1.0 - i / 59.0                  # 1.0 -> 0.0
    mix = cv2.addWeighted(day, alpha, night, 1.0 - alpha, 0.0)
    frames.append(mix)

# Watermarking is the same operation with a high alpha:
logo_bg = cv2.addWeighted(day, 0.92, np.full_like(day, 255), 0.08, 0.0)

Blending has a second life far from video editing: averaging $N$ aligned noisy frames divides the noise standard deviation by $\sqrt{N}$, the cheapest denoiser ever invented and a staple of astrophotography and microscopy (a theme developed properly in Chapter 7).

Why a square root rather than a plain $N$? The true scene is identical in every frame, so averaging leaves it untouched, while the noise is random and independent from frame to frame, so it adds in variance rather than in amplitude. Averaging $N$ samples of variance $\sigma^2$ yields a result of variance $\sigma^2 / N$, and taking the square root to get back to a standard deviation gives the $\sqrt{N}$ law. This is the same variance-adds, not-standard-deviations bookkeeping that drove the between-class variance decomposition in Section 2.4. Watch how fast that buys clean pixels: averaging just 4 frames halves the noise, and 16 frames quarters it, which is why an astrophotographer stacks a hundred exposures of the same galaxy and pulls a clean image out of what looked like pure grain in any single shot.

The same blending formula has a third life in deep learning. The mixup augmentation blends pairs of training images (and their labels) with a random $\alpha$, exactly this section's convex combination deployed as a regularizer, which we will meet among the training recipes of Chapter 21.

3. Difference Images: Seeing Change Intermediate

Subtracting two aligned images of the same scene isolates what changed between them. With a clean reference frame (an empty corridor, a bare conveyor belt), cv2.absdiff against the live frame highlights everything new, and a threshold from Section 2.4 turns the difference into a binary change mask. This three-line pattern is the ancestral form of motion detection and still runs in countless deployed systems:

# Frame differencing, the ancestral motion detector: absolute difference
# against a reference frame, a binary threshold on the change magnitude,
# and a changed-area fraction that triggers only on meaningful motion.
import cv2

background = cv2.imread("empty_corridor.png", cv2.IMREAD_GRAYSCALE)
frame      = cv2.imread("corridor_now.png",  cv2.IMREAD_GRAYSCALE)

diff = cv2.absdiff(frame, background)              # |frame - background|
_, motion_mask = cv2.threshold(diff, 25, 255, cv2.THRESH_BINARY)

changed_fraction = motion_mask.mean() / 255.0
if changed_fraction > 0.02:                        # >2% of pixels changed
    print(f"motion: {changed_fraction:.1%} of frame")   # e.g. motion: 7.3%

The static-reference assumption is, predictably, the weak point: lighting drifts, trees sway, and the "empty" scene never stays empty. Production systems therefore maintain a running statistical model of the background per pixel (OpenCV ships cv2.createBackgroundSubtractorMOG2, a per-pixel Gaussian mixture), and the full story of motion, including optical flow that estimates where each pixel went rather than just whether it changed, belongs to Chapter 15.

4. Alpha Compositing: The Over Operator Advanced

Blending with one global $\alpha$ dissolves whole images into each other. Compositing generalizes $\alpha$ into a per-pixel coverage map: a fourth channel, the alpha channel, where 1 means fully opaque, 0 fully transparent, and fractions mean partial coverage (the soft edge of hair, the translucency of glass, the antialiased boundary of a rendered logo). Porter and Duff's 1984 paper defined an algebra of twelve ways to combine two such images; the one that conquered the world is over. Placing foreground $F$ (color $C_f$, alpha $\alpha_f$) over background $B$ (color $C_b$, alpha $\alpha_b$):

$$\alpha_o = \alpha_f + \alpha_b (1 - \alpha_f), \qquad C_o = \frac{\alpha_f C_f + \alpha_b C_b (1 - \alpha_f)}{\alpha_o}$$

The structure is exactly what physical intuition demands: the foreground contributes in proportion to its coverage $\alpha_f$, and the background shows through only the remaining $(1 - \alpha_f)$. With an opaque background ($\alpha_b = 1$), the color formula collapses to the familiar $C_o = \alpha_f C_f + (1 - \alpha_f) C_b$. To make that concrete, place a half-covered white edge pixel ($C_f = 255$, $\alpha_f = 0.5$) over a black background ($C_b = 0$): the result is $0.5 \cdot 255 + 0.5 \cdot 0 = 128$, a mid-gray, which is exactly the soft antialiased boundary you see when a white shape meets a dark backdrop. Figure 2.5.1 traces the operator's data flow.

The implementation below covers the overwhelmingly common case of an opaque background, where the division by $\alpha_o$ disappears. Watch the imread flag: OpenCV's default loader silently drops the alpha channel that the whole computation depends on.

# Porter-Duff 'over' for the common opaque-background case: blend a BGRA
# foreground onto a BGR background by its per-pixel alpha. Note the
# IMREAD_UNCHANGED flag: the default loader drops the alpha this needs.
import numpy as np
import cv2

def composite_over(fg_bgra, bg_bgr):
    """Porter-Duff 'over' for a BGRA foreground on an opaque BGR background."""
    fg = fg_bgra[..., :3].astype(np.float32)
    alpha = (fg_bgra[..., 3:4].astype(np.float32)) / 255.0   # (H, W, 1)
    bg = bg_bgr.astype(np.float32)
    out = alpha * fg + (1.0 - alpha) * bg       # broadcast over channels
    return np.clip(out, 0, 255).astype(np.uint8)

overlay = cv2.imread("score_banner.png", cv2.IMREAD_UNCHANGED)  # keeps alpha!
frame   = cv2.imread("match_frame.jpg")
print(overlay.shape)        # (H, W, 4): the 4th channel is alpha
shown = composite_over(overlay, frame)

from PIL import Image
out = Image.alpha_composite(bg_rgba, fg_rgba)    # both in RGBA mode

5. Masks and Bitwise Operations Intermediate

When transparency is all-or-nothing, the binary masks produced by the thresholding of Section 2.4 take the place of a fractional alpha channel, and compositing reduces to bitwise logic: AND to keep pixels where the mask is set, AND with the inverted mask to punch a hole, OR to merge the pieces. OpenCV's bitwise_* family accepts an 8-bit mask argument that gates the operation per pixel, giving the classic hard-edged logo overlay:

# Hard-mask compositing when transparency is all-or-nothing: Otsu builds
# the logo's binary mask, two bitwise_and operations carve the frame hole
# and extract the logo pixels, and a saturating add welds them together.
import cv2

frame = cv2.imread("match_frame.jpg")
logo  = cv2.imread("club_logo.png")            # opaque BGR logo on white

# Build a binary mask of the logo's own pixels (Otsu, inverted: logo is dark)
logo_gray = cv2.cvtColor(logo, cv2.COLOR_BGR2GRAY)
_, mask = cv2.threshold(logo_gray, 0, 255,
                        cv2.THRESH_BINARY_INV + cv2.THRESH_OTSU)
mask_inv = cv2.bitwise_not(mask)

roi = frame[20:20 + logo.shape[0], 20:20 + logo.shape[1]]
hole  = cv2.bitwise_and(roi, roi, mask=mask_inv)   # background minus logo area
inked = cv2.bitwise_and(logo, logo, mask=mask)     # logo pixels only
frame[20:20 + logo.shape[0], 20:20 + logo.shape[1]] = cv2.add(hole, inked)

This bitwise idiom is the workhorse of region-of-interest processing throughout the rest of the book: masks select which pixels an operation may touch, whether that operation is a histogram (the mask argument of cv2.calcHist in Section 2.2), a color correction, or a generative edit. The masks themselves will get vastly smarter, produced by morphology in Chapter 6 and by segmentation networks later, but the compositing algebra they plug into is the one on this page. Two previews of where this leads: blending with a soft mask across a seam is done far better at multiple scales with the pyramids of Chapter 4, and the modern generative version of "put this object into that photo" appears in Chapter 35.

Every tool in this chapter now sits in your hands: tone curves that fix exposure, histograms that diagnose it, equalization and CLAHE that boost local contrast, Otsu and adaptive thresholds that turn pixels into decisions, and the compositing algebra above that recombines them. The Hands-On Lab at the end of this section asks you to wire all five into one program, an automatic document cleanup tool that decides what each scan needs and proves the decision with a side-by-side panel.

import sys, cv2, numpy as np

def load_gray(path):
    bgr = cv2.imread(path, cv2.IMREAD_COLOR)
    if bgr is None:
        sys.exit(f"could not read {path}")
    return bgr, cv2.cvtColor(bgr, cv2.COLOR_BGR2GRAY)

def stats(gray):
    hist = cv2.calcHist([gray], [0], None, [256], [0, 256]).ravel()
    p = hist / hist.sum()                     # normalized histogram (a distribution)
    cdf = np.cumsum(p)
    # TODO: return a dict with keys "mean", "p05", "p95", "entropy".
    # Hint: mean is float(gray.mean()); p05/p95 are the intensities where cdf
    # first crosses 0.05 and 0.95 (use np.searchsorted); entropy is
    # -sum(p * log2(p)) over the nonzero bins.

def build_tone_lut(s):
    x = np.arange(256, dtype=np.float32)
    # Percentile stretch: map [p05, p95] to roughly [10, 245].
    lo, hi = s["p05"], max(s["p95"], s["p05"] + 1)
    stretched = (x - lo) * (235.0 / (hi - lo)) + 10.0
    # TODO: pick a gamma from the mean. If the scan is dark (mean < 110),
    #       use gamma < 1 to lift shadows; otherwise use gamma = 1.0.
    # Hint: normalize stretched to [0,1], raise to (1/gamma), scale back to [0,255].
    gamma = 1.0  # replace this line using s["mean"]
    norm = np.clip(stretched, 0, 255) / 255.0
    out = np.power(norm, 1.0 / gamma) * 255.0
    return np.clip(out, 0, 255).astype(np.uint8)

def local_contrast(toned):
    # TODO: construct a CLAHE operator with clipLimit=2.5 and tileGridSize=(8, 8),
    #       then return its .apply() result on the toned grayscale image.
    pass

def binarize(enhanced, s):
    even_light = (s["p95"] - s["p05"]) > 60   # wide spread suggests usable global contrast
    if even_light:
        _, binary = cv2.threshold(enhanced, 0, 255,
                                  cv2.THRESH_BINARY + cv2.THRESH_OTSU)
        method = "otsu"
    else:
        # TODO: use cv2.adaptiveThreshold (Gaussian, blockSize=41, C=10)
        #       to produce a binary image; set method = "adaptive".
        binary, method = None, "adaptive"
    return binary, method

def panel(gray, enhanced, binary, method):
    tiles = [gray, enhanced, binary]
    labels = ["original", "enhanced", f"binary ({method})"]
    h = min(t.shape[0] for t in tiles)
    tiles = [cv2.resize(t, (int(t.shape[1] * h / t.shape[0]), h)) for t in tiles]
    # TODO: write each label onto its tile with cv2.putText, then
    #       horizontally concatenate the three tiles with np.hstack
    #       and return the result.
    pass

def main(path):
    bgr, gray = load_gray(path)
    s = stats(gray)
    toned = cv2.LUT(gray, build_tone_lut(s))
    enhanced = local_contrast(toned)
    binary, method = binarize(enhanced, s)
    print(f"mean={s['mean']:.1f} spread={s['p95'] - s['p05']} method={method}")
    cv2.imwrite("clean_page.png", binary)
    cv2.imwrite("comparison.png", panel(gray, enhanced, binary, method))

if __name__ == "__main__":
    main(sys.argv[1] if len(sys.argv) > 1 else "scan.jpg")

import sys, cv2, numpy as np

def load_gray(path):
    bgr = cv2.imread(path, cv2.IMREAD_COLOR)
    if bgr is None:
        sys.exit(f"could not read {path}")
    return bgr, cv2.cvtColor(bgr, cv2.COLOR_BGR2GRAY)

def stats(gray):
    hist = cv2.calcHist([gray], [0], None, [256], [0, 256]).ravel()
    p = hist / hist.sum()
    cdf = np.cumsum(p)
    nz = p[p > 0]
    return {
        "mean": float(gray.mean()),
        "p05": int(np.searchsorted(cdf, 0.05)),
        "p95": int(np.searchsorted(cdf, 0.95)),
        "entropy": float(-(nz * np.log2(nz)).sum()),
    }

def build_tone_lut(s):
    x = np.arange(256, dtype=np.float32)
    lo, hi = s["p05"], max(s["p95"], s["p05"] + 1)
    stretched = (x - lo) * (235.0 / (hi - lo)) + 10.0     # percentile stretch
    gamma = 0.6 if s["mean"] < 110 else 1.0               # lift shadows if dark
    norm = np.clip(stretched, 0, 255) / 255.0
    out = np.power(norm, 1.0 / gamma) * 255.0
    return np.clip(out, 0, 255).astype(np.uint8)

def local_contrast(toned):
    clahe = cv2.createCLAHE(clipLimit=2.5, tileGridSize=(8, 8))
    return clahe.apply(toned)

def binarize(enhanced, s):
    even_light = (s["p95"] - s["p05"]) > 60
    if even_light:
        _, binary = cv2.threshold(enhanced, 0, 255,
                                  cv2.THRESH_BINARY + cv2.THRESH_OTSU)
        return binary, "otsu"
    binary = cv2.adaptiveThreshold(enhanced, 255,
                                   cv2.ADAPTIVE_THRESH_GAUSSIAN_C,
                                   cv2.THRESH_BINARY, 41, 10)
    return binary, "adaptive"

def panel(gray, enhanced, binary, method):
    tiles = [gray, enhanced, binary]
    labels = ["original", "enhanced", f"binary ({method})"]
    h = min(t.shape[0] for t in tiles)
    tiles = [cv2.resize(t, (int(t.shape[1] * h / t.shape[0]), h)) for t in tiles]
    for tile, text in zip(tiles, labels):
        cv2.putText(tile, text, (10, 30),
                    cv2.FONT_HERSHEY_SIMPLEX, 1.0, 0, 2)
    return np.hstack(tiles)

def main(path):
    bgr, gray = load_gray(path)
    s = stats(gray)
    toned = cv2.LUT(gray, build_tone_lut(s))
    enhanced = local_contrast(toned)
    binary, method = binarize(enhanced, s)
    print(f"mean={s['mean']:.1f} spread={s['p95'] - s['p05']} method={method}")
    cv2.imwrite("clean_page.png", binary)
    cv2.imwrite("comparison.png", panel(gray, enhanced, binary, method))

if __name__ == "__main__":
    main(sys.argv[1] if len(sys.argv) > 1 else "scan.jpg")
